5CGTFD9E5F35I7N

Overview

DK-DEV-5CGTD9N is a development kit manufactured by Altera, designed for prototyping the Cyclone V GT FPGA. It specifically targets the evaluation of the 5CGTD9-C7N device variant. The kit supports SDI interface applications and operates on a power supply voltage ranging from 14 V to 20 V. Classified under Programmable Logic IC Development Tools within the Cyclone V GX Development Kits series, this tool facilitates hardware validation for high-speed transceiver designs.

Feature Summary

• Designed for rapid prototyping of Cyclone V GT FPGAs
• Supports SDI interface application development
• Validates specific 5CGTD9-C7N device variants

Applications

• Cyclone V GT FPGA hardware prototyping
• SDI interface design verification
• Development kit evaluation for 5CGTD9-C7N

Procurement Notes

Verify component authenticity through authorized Intel/Altera distributors or official documentation channels. Confirm that the part number DK-DEV-5CGTD9N matches the intended Cyclone V GT development requirements. Check for obsolescence status as indicated in public databases before procurement planning.

Selection Notes

Select this kit only if the target design requires the 5CGTD9-C7N Cyclone V GT FPGA. Ensure the system power supply accommodates the 14 V to 20 V operating range. Verify compatibility with SDI interface protocols prior to acquisition.

Part Context

This development kit belongs to the Cyclone V family, which utilizes TSMC's 28 nm low-power process technology. The Cyclone V GT variant is optimized for 6.144 Gbps transceiver applications, offering industry-leading cost and power efficiency for high-bandwidth designs.

Replacement Considerations

Public confirmed substitute part numbers are not available.
