5SGSED6K3F40I3L

Overview

The Altera 5SGSED6K3F40I3L is a Stratix V GS Field Programmable Gate Array (FPGA) designed for high-density logic applications. It features 583,000 logic elements and 220,000 adaptive logic modules (ALMs). The device integrates 45 Mbit of embedded memory and supports up to 696 I/Os. It operates within a junction temperature range of 0°C to 85°C and utilizes an 870 mV to 930 mV core voltage supply. Packaged in a 1517-ball FCBGA, it is suitable for complex digital signal processing and control systems.

Feature Summary

• Stratix V GS architecture with 583,000 LEs and 220,000 ALMs
• Integrated 45 Mbit embedded memory capacity
• Supports 696 I/O pins in a 1517-ball FCBGA package
• Operates at 0°C to 85°C junction temperature

Applications

• High-performance digital signal processing
• Industrial automation control systems
• Telecommunications infrastructure equipment

Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status and moisture sensitivity level (MSL 3) prior to handling. Check for specific manufacturing date codes and lot traceability required for quality assurance protocols.

Selection Notes

Select this model when requiring the specific Stratix V GS density of 583k LEs. Ensure design compatibility with the 1517-ball FCBGA footprint. Verify that the 0-85°C operating range meets environmental requirements. Compare against other 5SGSED6K variants if different temperature grades or packaging options are needed.

Part Context

This part belongs to the Stratix V GS family, which offers high logic density optimized for cost-sensitive high-volume applications. It shares architectural similarities with the GX series but focuses on general-purpose logic rather than high-speed transceivers. It succeeds earlier Stratix generations while preceding the Agilex product line.

Replacement Considerations

Direct pin-to-pin replacements may not exist due to unique package and feature sets. Consider upgrading to Agilex 5 or Stratix 10 families for modern equivalents, though these require significant design re-verification and potentially new PCB layouts.
