Product Detailed Parameters
- Description：IC INVERTER
- Series：*
- Mfr：Nexperia USA Inc.
- Package：Bulk
- Logic Type：-
- Number of Circuits：-
- Number of Inputs：-
- Features：-
- Voltage - Supply：-
- Current - Quiescent (Max)：-
- Current - Output High, Low：-
- Input Logic Level - Low：-
- Input Logic Level - High：-
- Max Propagation Delay @ V, Max CL：-
- Operating Temperature：-
- Mounting Type：-
- Supplier Device Package：-
- Package / Case：-
- Grade：-
- Qualification：-
Download product information
Overview
The Nexperia 74HC3G14GD,125 is a triple inverting Schmitt trigger IC manufactured by Nexperia USA Inc. It operates within a supply voltage range of 2.0 V to 6.0 V and supports an ambient temperature range from -40 °C to +125 °C. The device features CMOS low power dissipation, high noise immunity, and unlimited input rise and fall times. Latch-up performance exceeds 100 mA per JESD 78 Class II Level B. ESD protection meets ANSI/ESDA/JEDEC JS-001 class 2 (exceeds 2000 V HBM) and JS-002 class C3 (exceeds 1000 V CDM).
Feature Summary
- Triple inverter with Schmitt-trigger inputs for jitter-free output signals.
- Wide supply voltage range from 2.0 V to 6.0 V.
- Inputs include clamp diodes for interfacing with voltages exceeding VCC.
Applications
- Wave and pulse shaper for highly noisy environments
- Astable multivibrators
- Monostable multivibrators
Procurement Notes
Verify the specific ordering suffix against the manufacturer's current documentation to confirm package type and availability. Confirm RoHS compliance status and environmental certifications prior to procurement. Ensure the component matches the required logic family specifications for the intended design application.
Selection Notes
Select this component when a triple inverter with Schmitt-trigger action is required for signal conditioning. The wide supply voltage range allows compatibility with various system power rails. Verify that the operating temperature range meets the environmental requirements of the target application.
Part Context
This part belongs to the 74HC/HCT3G14 series of triple inverters with Schmitt-trigger inputs. It is designed for applications requiring noise immunity and clean signal transitions. The device is specified for industrial temperature ranges and offers robust latch-up protection.
Replacement Considerations
Check for direct pin-compatible alternatives within the same logic family. Verify that any substitute maintains the required Schmitt-trigger characteristics and supply voltage range. Ensure the replacement part meets the same ESD and latch-up performance standards.
