74LVCH162374ADL:11

Overview

The 74LVCH162374ADL:11 is a dual 8-bit D-type flip-flop with output latches, manufactured by Nexperia USA Inc. It belongs to the LVCH logic family, designed for 1.2 V to 3.6 V operation. The device features non-inverting inputs and outputs, supporting single-ended input types. It operates within a temperature range of -40 °C to +125 °C. The component utilizes a TSSOP-48 package, providing surface-mount installation. Propagation delay is specified at 3.8 ns at 3.3 V. High-level output current reaches -12 mA. This configuration supports high-speed data storage applications in low-voltage digital systems.

Feature Summary

• Dual 8-bit D-type flip-flop architecture with output latching capability
• LVCH series design optimized for 1.2 V to 3.6 V supply voltage ranges
• Non-inverting signal path with single-ended input compatibility
• Industrial temperature specification ensuring reliability from -40 °C to +125 °C

Applications

• High-speed data bus interfacing requiring parallel storage
• Low-voltage digital system clock synchronization circuits
• Portable electronic devices operating on limited power supplies
• Industrial control systems requiring wide temperature tolerance

Procurement Notes

Verify the specific ordering suffix :11 against official Nexperia documentation to confirm tape and reel packaging specifications. Confirm RoHS compliance status through current datasheets. Check availability status as distribution channels may vary. Ensure the TSSOP-48 package variant matches your PCB footprint requirements. Validate lead-free soldering compatibility for assembly processes.

Selection Notes

Select this component when designing systems requiring dual 8-bit parallel data storage with latch functionality. The LVCH family offers suitable performance for mixed 5 V and 3.3 V environments due to its voltage tolerance. Consider the TSSOP-48 package constraints regarding board space and thermal management. Evaluate propagation delay characteristics against your system timing requirements. Ensure power supply stability within the 1.2 V to 3.6 V operational window.

Part Context

This part belongs to the Nexperia 74LVCH series, which provides low-voltage CMOS logic solutions. The LVCH family is engineered for high-speed operation while maintaining low power consumption. It serves as a bridge between traditional 5 V logic and modern low-voltage standards. The 74LVCH162374 specifically addresses needs for parallel data handling in compact form factors. Its industrial grade rating extends applicability beyond consumer electronics.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Verify cross-reference options directly with Nexperia technical support or authorized distributors. Ensure any replacement maintains identical pinout, voltage range, and package dimensions. Confirm functional equivalence for dual 8-bit D-type flip-flop operations.
