7WA0000008

Oscillators Overview

The TXC Corporation 7WA0000008 is a standard CMOS crystal oscillator operating at a frequency of 100 MHz. It utilizes a crystal base resonator and provides a CMOS output signal. The device supports a supply voltage range of 1.8V to 3.3V and features a frequency stability of ±50 ppm. It operates within an industrial temperature range of -40°C to +85°C. The component is housed in a compact 4-SMD, no-lead package with dimensions of 2.50mm x 2.00mm.

Oscillators Feature Summary

• Generates a precise 100 MHz clock signal using a crystal base resonator for stable timing applications.
• Supports flexible power supply requirements ranging from 1.8V to 3.3V for diverse system integration.
• Ensures reliable operation across the full industrial temperature spectrum from -40°C to +85°C.
• Features a low-profile surface-mount package design suitable for space-constrained circuit boards.

Oscillators Applications

• Industrial control systems requiring robust clock sources
• Data acquisition hardware and measurement instruments
• Communication equipment and network interface modules
• Embedded computing platforms and microcontroller systems

Oscillators Procurement Notes

Verify the specific voltage variant required for your application, as the part supports both 1.8V and 3.3V operations. Confirm that the ±50 ppm frequency stability meets your system's timing tolerance requirements. Ensure the PCB footprint matches the 4-SMD no-lead package dimensions of 2.50mm by 2.00mm. Check for any RoHS compliance documentation if your manufacturing process requires strict environmental adherence. Validate the operating temperature range against your intended deployment environment.

Oscillators Selection Notes

Select this oscillator when a high-frequency 100 MHz clock is needed with moderate stability. Consider it for designs requiring wide voltage compatibility between 1.8V and 3.3V. Choose this model for industrial environments where temperatures may fluctuate significantly. Evaluate the package size constraints to ensure the 4-SMD form factor fits your layout. Compare against other series if tighter frequency stability or different output types are necessary.

Oscillators Part Context

This component belongs to the TXC 7W series of standard oscillators, designed for general-purpose timing applications. The series offers various frequencies and packages to support different electronic product needs. The 7WA0000008 specifically targets high-speed digital circuits requiring a reliable 100 MHz reference. It complements TXC's broader portfolio of crystals and resonators by providing integrated oscillator solutions.

Oscillators Replacement Considerations

Public confirmed substitute part numbers are not available in the provided data. Consult official distributor databases for cross-reference information. Verify pinout compatibility and electrical parameters before considering alternative components. Ensure any replacement meets the same industrial temperature and voltage specifications.
