895-054-558-103 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE SINGLE FML 54POS 0.100. Review the specifications below when checking this part for your BOM.
Edgeboard Connectors specifications for 895-054-558-103
- Description：CONN EDGE SINGLE FML 54POS 0.100
- Series：895
- Mfr：EDAC Inc.
- Package：Bulk
- Card Type：Non Specified - Single Edge
- Gender：Female
- Number of Positions/Bay/Row：54
- Number of Positions：54
- Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
- Number of Rows：1
- Pitch：0.100" (2.54mm)
- Read Out：Single
- Features：-
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Contact Material：Copper Alloy
- Contact Finish：Gold
- Contact Finish Thickness：10.0µin (0.25µm)
- Contact Type：Cantilever
- Color：Black
- Flange Feature：Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia
- Operating Temperature：-40°C ~ 125°C
Edgeboard Connectors datasheet and documents for 895-054-558-103
Edgeboard Connectors Overview
The EDAC Inc. 895-054-558-103 is a single-edge female card edge connector featuring 54 positions with a 0.100-inch (2.54mm) pitch. Designed for panel mount installation, it utilizes gold-plated copper alloy contacts and a polyphenylene sulfide (PPS) insulator. The component supports a PCB thickness of 1.57mm and operates within a temperature range of -40°C to +125°C. It complies with RoHS3 standards and carries an MSL rating of 1.
Edgeboard Connectors Feature Summary
- Single-row receptacle configuration for standard card edge applications
- Gold-plated contacts ensure reliable signal transmission
- Polyphenylene sulfide housing provides thermal stability
Edgeboard Connectors Applications
- Industrial control systems
- Telecommunications equipment
- Automotive electronics
Edgeboard Connectors Procurement Notes
Verify the specific ordering suffix against the manufacturer's official datasheet to confirm mechanical orientation and termination style. Ensure compatibility with the target printed circuit board thickness of 1.57mm before procurement. Confirm that the single-edge design aligns with the system architecture requirements.
Edgeboard Connectors Selection Notes
Select this component when a single-sided connection interface is required for high-density signal routing. The 0.100-inch pitch accommodates standard trace widths. Verify that the panel mount style fits the enclosure constraints and that the operating temperature range meets environmental specifications.
Edgeboard Connectors Part Context
This part belongs to the EDAC 895 series, which specializes in standard card edge connectors. The series offers various position counts and mounting styles. The 895-054 variant specifically addresses mid-range density needs with a robust mechanical design suitable for repeated insertion cycles.
Edgeboard Connectors FAQ
What is the maximum operating temperature?
The connector is rated for operation up to +125°C.
Is the connector double-sided or single-sided?
It is a single-edge female connector designed for one-sided card insertion.
