AA.170.301111

$23.60

Description：RF ANT 1.561/1.575GHZ CER PATCH
Series：Magma
Mfr：Taoglas Limited
Package：Bag

SKU:1f312d43e03f Category: RF Antennas Brand: Taoglas Limited

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF ANT 1.561/1.575GHZ CER PATCH
Series：Magma
Mfr：Taoglas Limited
Package：Bag
RF Family/Standard：Navigation
Frequency Group：UHF (1GHz ~ 2GHz)
Frequency (Center/Band)：1.561GHz, 1.575GHz, 1.602GHz
Frequency Range：1.559GHz ~ 1.61GHz
Antenna Type：Ceramic Patch
Number of Bands：3
VSWR：2
Return Loss：-
Gain：5.76dBi, 4.46dBi, 5.98dBi
Features：Cable - 3m, LNA, Filter
Termination：SMA Male
Ingress Protection：IP65
Grade：-
Qualification：-
Mounting Type：Magnetic
Height (Max)：0.673" (17.10mm)
Applications：Beidou, GLONASS, GPS
Power - Max：-

Download product information

AA.170.301111

Overview

The AA.170.301111 is a multi-band GNSS ceramic patch antenna manufactured by Taoglas Limited, designed for outdoor and automotive applications. It supports GPS, GLONASS, Galileo, and BeiDou constellations across the UHF frequency group (1GHz ~ 2GHz). The unit features an integrated Low Noise Amplifier (LNA) and filter, connected via a 3-meter cable with an SMA male connector. Key specifications include a center frequency of 1.561GHz/1.575GHz/1.602GHz, a gain of 4.4 dBi, and an IP67 rating for environmental protection.

Feature Summary

Supports multiple global navigation satellite systems including GPS, GLONASS, Galileo, and BeiDou
Integrated active components comprising a Low Noise Amplifier and signal filter
IP67 rated enclosure suitable for harsh outdoor and automotive environments
Compact square ceramic patch design optimized for space-constrained installations

Applications

Advanced telematics systems
Fleet management tracking
Automotive navigation units
Outdoor positioning devices

Procurement Notes

Verify that the replacement part number matches the specific SMA male connector configuration and 3-meter cable length required by the system design. Confirm that the active LNA integration aligns with the receiver's power supply capabilities and impedance requirements. Ensure the IP67 rating meets the environmental exposure standards of the intended installation site to guarantee long-term reliability.

Selection Notes

Select this model when multi-constellation support is required alongside high environmental durability. The integrated LNA and filter simplify the RF front-end design by reducing component count. The magnetic mounting option facilitates rapid deployment on metal surfaces without permanent modification. Consider the 3-meter cable length as a fixed constraint during layout planning.

Part Context

This component belongs to the Magma series of GNSS antennas from Taoglas Limited. It serves as an upgrade or alternative to passive ceramic patch solutions by providing active signal amplification. The product line targets the automotive and industrial sectors where robust connectivity and precise location data are critical for operational efficiency.
