ACG0301U

Antennas RF Overview

The ACG0301U is a surface-mount Ultra-Wide Band (UWB) chip antenna manufactured by Abracon LLC. It operates within the frequency range of 6.2 GHz to 8.2 GHz, specifically covering 6220 MHz to 8200 MHz. The component features linear polarization and is designed for compact integration in electronic devices. It complies with RoHS3 standards and carries an EAR99 classification. The antenna supports MSL Level 1 moisture sensitivity.

Antennas RF Feature Summary

• Ultra-wideband operation across the 6.2 GHz to 8.2 GHz spectrum
• Linear polarization for consistent signal transmission
• Compact surface-mount design suitable for space-constrained applications

Antennas RF Applications

• Short-range wireless communication systems
• Ultra-wideband positioning and tracking devices
• Consumer electronics requiring high-speed data transfer

Antennas RF Procurement Notes

Verify that the specific procurement channel provides original manufacturer documentation to confirm authenticity. Ensure the received components match the specified UWB frequency range and physical dimensions. Check for compliance with environmental regulations such as RoHS3 before integration into final products.

Antennas RF Selection Notes

Select this component when designing circuits requiring ultra-wideband capabilities within the 6.2 to 8.2 GHz band. Consider its surface-mount form factor for PCB layout efficiency. Evaluate the linear polarization characteristics against system requirements for signal integrity and interference rejection in dense RF environments.

Antennas RF Part Context

This antenna belongs to Abracon's portfolio of high-performance UWB antennas, which includes models like ACG0502U and ACG0806U. These components are engineered to support modern short-range wireless technologies, offering reliable performance in various consumer and industrial applications.
