AD8517ARTZ-REEL7

Overview

The AD8517ARTZ-REEL7 is a single-channel, rail-to-rail input and output operational amplifier manufactured by Analog Devices. It operates on a single supply voltage ranging from 1.8 V to 6 V. The device features a gain bandwidth product of 7 MHz and a slew rate of 8 V/µs. Typical offset voltage is 1.3 mV with a maximum of 3.5 mV at room temperature. Supply current is typically 900 µA at 5 V. It is housed in a 5-lead SOT-23 package and supports an operating temperature range of -40°C to +125°C.

Feature Summary

• Rail-to-rail input and output capability allows full signal swing across the entire supply voltage range.
• Low supply current consumption makes it suitable for battery-powered applications.
• High slew rate and wide bandwidth support fast signal processing requirements.
• Small SOT-23 package facilitates placement near sensors to minimize noise pickup.

Applications

• Portable communications equipment
• Sensor interface circuits
• Active filters
• ASIC input drivers
• Battery-powered devices

Procurement Notes

Verify the specific ordering suffix ARTZ corresponds to the 5-lead SOT-23 package variant. Confirm that the REEL7 designation matches the required tape and reel quantity specifications for your manufacturing process. Ensure the component meets the extended industrial temperature range requirements if operating outside standard commercial limits.

Selection Notes

Select this component when space constraints require a small surface-mount package alongside high-speed performance needs. It is appropriate for designs requiring rail-to-rail signal handling at low supply voltages. Consider the input bias current characteristics when interfacing with high-impedance sources to ensure minimal offset errors.

Part Context

This part belongs to the AD85x7 family of low-voltage operational amplifiers. The AD8517 represents the single-channel version, while the AD8527 provides dual channels. Both utilize Analog Devices' XFCB complementary bipolar process to achieve high speed and precision within compact packaging solutions.

Replacement Considerations

Direct functional equivalents include other single-channel rail-to-rail op-amps in SOT-23-5 packages. Verify pinout compatibility and electrical parameters such as bandwidth and supply current before substitution.
