AGGBP.SLS.18A.07.0060A

$19.45

Description：5.9GHZ DSRC / C-V2X PATCH ANTENN
Series：-
Mfr：Taoglas Limited
Package：Tray

SKU:45cd5fd809e9 Category: RF Antennas Brand: Taoglas Limited

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AGGBP.SLS.18A.07.0060A is listed in the Antennas RF range at ChipApex. The manufacturer field lists Taoglas Limited. Its product description is 5.9GHZ DSRC / C-V2X PATCH ANTENN. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for AGGBP.SLS.18A.07.0060A

Description：5.9GHZ DSRC / C-V2X PATCH ANTENN
Series：-
Mfr：Taoglas Limited
Package：Tray
RF Family/Standard：Navigation
Frequency Group：UHF (1GHz ~ 2GHz)
Frequency (Center/Band)：1.561GHz, 1.575GHz, 1.602GHz
Frequency Range：-
Antenna Type：Ceramic Patch
Number of Bands：3
VSWR：-
Return Loss：-
Gain：1dBi, 1.38dBi, 1.15dBi
Features：Cable - 60mm, LNA, Filter
Termination：U.FL (UMCC), I-PEX MHF1
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Surface Mount
Height (Max)：0.337" (8.57mm)
Applications：Beidou, Galileo, GLONASS, GNSS, GPS
Power - Max：-

Antennas RF datasheet and documents for AGGBP.SLS.18A.07.0060A

AGGBP.SLS.18A.07.0060A

Antennas RF Overview

The AGGBP.SLS.18A.07.0060A is an active GNSS patch antenna designed for internal integration in mobile devices and navigation equipment. It supports GPS, GLONASS, Galileo, and BeiDou constellations with a center frequency of 1.5754 GHz and a maximum operating frequency of 1.602 GHz. The component features a built-in Low Noise Amplifier (LNA) providing 13.0 dB to 14.5 dB gain, alongside Surface Acoustic Wave (SAW) filters for enhanced out-of-band rejection. It utilizes an I-PEX MHF IU.FL connector interface and measures 18 mm in length with a height of 4 mm.

Antennas RF Feature Summary

Integrated active circuitry combining LNA and SAW filters for signal amplification and interference rejection
Multi-constellation support enabling reception across GPS, GLONASS, Galileo, and BeiDou satellite systems
Compact surface-mount form factor suitable for space-constrained internal device applications

Antennas RF Applications

Smartphones and mobile communication devices requiring integrated GNSS positioning
Portable navigation units and automotive telematics systems
IoT modules and wearable technology utilizing multi-constellation location services

Antennas RF Procurement Notes

Verify the specific LNA gain specification (13.0 dB or 14.5 dB) against the latest manufacturer datasheet revision prior to procurement. Confirm mechanical compatibility with the I-PEX MHF IU.FL connector system on the target PCB layout. Ensure environmental ratings meet operational temperature requirements for the intended deployment scenario.

Antennas RF Selection Notes

Select this component when high sensitivity and interference rejection are critical for indoor or urban canyon environments. The integrated SAW filters provide superior performance compared to passive alternatives in noisy RF spectra. Evaluate the 18 mm footprint against available board space constraints within the host enclosure design.

Antennas RF Part Context

This model belongs to Taoglas Limited's portfolio of active GNSS antennas engineered for consumer electronics. It represents a specialized solution for multi-band satellite navigation, distinguishing itself from passive ceramic patches by incorporating active amplification stages to overcome insertion losses in compact internal installations.

Antennas RF Replacement Considerations

No direct public substitute part numbers are confirmed for this specific active configuration. Designers must evaluate alternative active patch antennas with matching connector types and LNA specifications if this component becomes unavailable.
