AGL125V5-QNG132

Overview

The AGL125V5-QNG132 is a Field Programmable Gate Array from the IGLOO family, manufactured by Microsemi. It features 125,000 system gates and 3,072 VersaTiles (D-flip-flops). The device operates with a core voltage of 1.5 V only and supports up to 143 user I/Os in its QN132 package. It includes 36 kbits of true dual-port SRAM organized into eight 4,608-bit blocks and one 1 kbit FlashROM block. The maximum system performance reaches 250 MHz at 1.5 V systems. The component utilizes a 130-nm flash-based CMOS process and offers Instant On Level 0 support.

Feature Summary

• Flash*Freeze technology enables ultra-low power consumption while maintaining FPGA content and data retention.
• Nonvolatile flash architecture provides Instant On capability without requiring external boot PROMs.
• Integrated security features include AES decryption for secure In-System Programming and FlashLock protection.
• Advanced I/O structure supports mixed-voltage operation across multiple banks with programmable slew rates.

Applications

• Portable electronics requiring low static and dynamic power consumption
• Systems needing instant-on functionality and rapid recovery from low-power modes
• Applications demanding secure remote field updates and intellectual property protection

Procurement Notes

Verify the specific ordering suffixes against the manufacturer's current datasheet to confirm voltage range and temperature grade. Ensure the QN132 package dimensions and pitch match the target PCB footprint requirements. Confirm RoHS compliance status if halogen-free packaging is required for the assembly process.

Selection Notes

Select this device when 125,000 system gates are sufficient for the design logic density. The 1.5 V-only core voltage requirement dictates the power supply design constraints. Consider the available 143 user I/Os and the specific pinout of the QN132 package during the initial schematic capture phase to avoid routing conflicts.

Part Context

This part belongs to the IGLOO Low Power Flash FPGA family, which is based on a 130-nm process. It shares architectural similarities with other devices in the series, such as the AGL060 and AGL250, but differs in gate count and memory resources. The QN132 package is a Quad Flat Pack No Leads configuration suitable for space-constrained designs.

Replacement Considerations

Check for direct pin-compatible upgrades within the IGLOO family, such as the AGL250 series, if higher capacity is needed. Verify that any substitute maintains the same 1.5 V core voltage specification and QN132 package footprint to ensure mechanical compatibility.
