Product Detailed Parameters
- Description：MOSFET N/P-CH 30V 12A TO252-4L
- Series：-
- Mfr：Alpha & Omega Semiconductor Inc.
- Package：Tape & Reel (TR)
- Technology：MOSFET (Metal Oxide)
- Configuration：N and P-Channel Complementary
- FET Feature：-
- Drain to Source Voltage (Vdss)：30V
- Current - Continuous Drain (Id) @ 25°C：12A (Tc)
- Rds On (Max) @ Id, Vgs：25mOhm @ 12A, 10V
- Vgs(th) (Max) @ Id：2.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs：25nC @ 10V
- Input Capacitance (Ciss) (Max) @ Vds：1250pF @ 15V
- Power - Max：2.1W
- Operating Temperature：-55°C ~ 175°C (TJ)
- Mounting Type：Surface Mount
- Package / Case：TO-252-5, DPAK (4 Leads + Tab), TO-252AD
- Supplier Device Package：TO-252-4L
- Grade：-
- Qualification：-
Download product information
Overview
The AOD607 is a complementary enhancement mode field effect transistor manufactured by Alpha & Omega Semiconductor Inc. It integrates N-channel and P-channel MOSFETs into a single package, utilizing advanced trench technology to achieve low on-resistance and reduced gate charge. This configuration supports efficient switching in high-frequency applications. The device is designed for surface mount installation, offering a compact solution for power management circuits where space efficiency and thermal performance are critical requirements.
Feature Summary
- Integrates complementary N-channel and P-channel MOSFETs in a single package
- Utilizes advanced trench technology for enhanced electrical performance
- Designed for low gate charge to support high-speed switching operations
Applications
- H-bridge motor control circuits
- Synchronous rectification in DC-DC converters
- Power management modules requiring complementary switching pairs
Procurement Notes
Verify component authenticity through authorized distribution channels. Confirm RoHS compliance status matches project environmental standards. Check datasheet revisions for any updates to electrical characteristics or packaging specifications before finalizing design integration.
Selection Notes
Evaluate the complementary pair configuration against discrete alternatives for board space constraints. Consider the specific RDS(on) values and gate charge parameters relative to the target switching frequency. Ensure thermal management strategies align with the package's dissipation capabilities under expected load conditions.
Part Context
This component belongs to Alpha & Omega Semiconductor's portfolio of discrete power devices. It complements their broader range of MOSFETs and power management solutions. The company focuses on integrating process technology with advanced packaging to address complex power requirements in consumer and industrial electronics.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Designers should consult official manufacturer resources for potential cross-reference options or updated product line replacements.
