Product Detailed Parameters
- Description：FILTER LC(PI) 1UF TH
- Series：B85321
- Mfr：EPCOS - TDK Electronics
- Package：Tray
- Voltage - Rated：600V
- Current：63 A
- Operating Temperature：-40°C ~ 85°C
- Mounting Type：Through Hole
- Package / Case：Axial - Threaded Terminals
- Size / Dimension：-
- Capacitance：-
- Tolerance：-
- DC Resistance (DCR) (Max)：-
- Insertion Loss：-
- Temperature Coefficient：-
- Ratings：-
- Height (Max)：-
- Thread Size：-
Download product information
Overview
The B85321A4205B630 is an EMI feedthrough filter manufactured by EPCOS, a TDK Electronics brand. It features axial threaded terminals for through-hole mounting and operates within a temperature range of -40°C to 85°C. The component is rated for 63A current and 440V AC voltage. Designed as a metallized self-healing film capacitor, it provides robust electromagnetic interference suppression in industrial power applications.
Feature Summary
- Provides effective EMI suppression for mains supply lines
- Utilizes axial threaded terminal design for secure panel mounting
- Constructed with metallized self-healing film technology
Applications
- Industrial machine power supplies
- Inverter input filtering
- Mains supply line protection
Procurement Notes
Verify the specific ordering suffix against official TDK Electronics documentation to ensure correct voltage and current ratings. Confirm package dimensions and terminal specifications match the mechanical constraints of the target assembly. Request updated datasheets directly from authorized distributors or the manufacturer to validate compliance with current RoHS and REACH standards before finalizing procurement orders.
Selection Notes
Select this component when high-current EMI filtration is required for single-phase AC systems. Ensure the operating environment stays within the specified -40°C to 85°C range. Verify that the 63A rated current aligns with the maximum load requirements of the application circuit to prevent thermal overload during continuous operation.
Part Context
This part belongs to the B85321 series of feedthrough filters designed for noise suppression in electrical networks. These components are integral to maintaining signal integrity and protecting sensitive electronics from conducted disturbances in industrial and commercial power distribution systems.
Replacement Considerations
Consult official substitution lists for compatible EMI filters with matching current and voltage ratings. Verify mechanical compatibility of threaded terminals before replacing.
