BAV20W RHG

$0.17

Description：DIODE STD 250V 200MA SOD123F
Series：-
Mfr：Taiwan Semiconductor Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:2fd9349082d7 Category: Single Diodes Brand: Taiwan Semiconductor Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：DIODE STD 250V 200MA SOD123F
Series：-
Mfr：Taiwan Semiconductor Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
Technology：Standard
Voltage - DC Reverse (Vr) (Max)：250 V
Current - Average Rectified (Io)：200mA
Voltage - Forward (Vf) (Max) @ If：1.25 V @ 200 mA
Speed：Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr)：50 ns
Current - Reverse Leakage @ Vr：100 nA @ 250 V
Capacitance @ Vr, F：5pF @ 0V, 1MHz
Mounting Type：Surface Mount
Package / Case：SOD-123F
Supplier Device Package：SOD-123F
Operating Temperature - Junction：-65°C ~ 150°C
Grade：-
Qualification：-

Download product information

BAV20W RHG

Overview

The BAV20W RHG is a standard silicon switching diode manufactured by Taiwan Semiconductor Corporation. It features a maximum DC reverse voltage of 150 V and an average forward rectified current of 200 mA. The device exhibits a maximum reverse leakage current of 100 nA at 150 V and a typical junction capacitance of 1.5 pF at 0 V and 1 MHz. Forward voltage drop is specified as 1.25 V at 200 mA, with a reverse recovery time of 50 ns. It operates within a junction temperature range of -65°C to +150°C and is housed in the SOD-323 surface-mount package.

Feature Summary

Utilizes planar technology for robust switching performance
Encapsulated in hermetically sealed leaded glass SOD-323 package
Designed for general-purpose applications in industrial equipment

Applications

Oscilloscopes
Digital voltmeters
Video output stages in color television

Procurement Notes

Verify the specific part number against official manufacturer documentation to confirm exact electrical ratings and package type. Ensure compatibility with design requirements regarding reverse voltage and current handling. Confirm RoHS compliance status through the latest datasheet before integration into production systems.

Selection Notes

Select this component for circuits requiring reliable small-signal switching with low leakage characteristics. The SOD-323 package offers compact surface-mount integration suitable for space-constrained designs. Evaluate thermal management needs based on the specified junction temperature limits during operation.

Part Context

This component belongs to the BAV20 series of general-purpose switching diodes fabricated using planar technology. These devices are designed for high reliability in various electronic applications, offering consistent performance across a wide operating temperature range while maintaining low forward voltage and fast recovery times.
