Product Detailed Parameters
- Description：NEXPERIA BCV63 - SMALL SIGNAL BI
- Series：*
- Mfr：Nexperia USA Inc.
- Package：Bulk
- Transistor Type：-
- Current - Collector (Ic) (Max)：-
- Voltage - Collector Emitter Breakdown (Max)：-
- Vce Saturation (Max) @ Ib, Ic：-
- Current - Collector Cutoff (Max)：-
- DC Current Gain (hFE) (Min) @ Ic, Vce：-
- Power - Max：-
- Frequency - Transition：-
- Operating Temperature：-
- Mounting Type：-
- Package / Case：-
- Supplier Device Package：-
- Grade：-
- Qualification：-
Download product information
Overview
The BCV63,215 is a dual NPN general-purpose transistor manufactured by Nexperia. It features matched pairs for high precision applications and is qualified under the AEC-Q101 automotive standard. The device operates with a maximum collector current of 100 mA and a maximum voltage of 30 V. It is housed in a compact SOT-363 surface-mount package, designed for low power consumption and efficient thermal performance in dense circuit layouts.
Feature Summary
- Matched pairs ensure consistent electrical characteristics between transistors
- AEC-Q101 qualification supports automotive reliability requirements
- Low voltage and current ratings suitable for sensitive signal processing
Applications
- Current mirrors requiring precise matching
- Temperature-independent working point circuits
- General-purpose switching and amplification in consumer electronics
Procurement Notes
Verify the specific suffix against official Nexperia documentation to confirm tape-and-reel specifications. Ensure compatibility with automated pick-and-place equipment regarding the SOT-363 footprint dimensions. Cross-reference the AEC-Q101 status if automotive grade validation is mandatory for the target application environment.
Selection Notes
Select this component when matched transistor performance is critical for circuit symmetry. The dual configuration reduces board space compared to discrete single transistors. Verify that the 30 V rating meets the system's peak voltage requirements without derating margins.
Part Context
This part belongs to the BCV6x series of dual NPN transistors. It shares the same internal structure as BCV61 and BCV62 but differs in pinout or specific matching criteria defined by the manufacturer. The series is optimized for applications requiring balanced pair performance in small packages.
Replacement Considerations
BCV61,215 and BCV62,215 are related parts within the same family. Verify pinout compatibility before substitution, as differences exist between the variants. Check datasheets for exact matching tolerances and AEC-Q101 compliance status.
