BSC020N03LSGATMA2 is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Infineon Technologies. Its product description is LV POWER MOS. Review the specifications below when checking this part for your BOM.
Single FETs, MOSFETs specifications for BSC020N03LSGATMA2
- Description：LV POWER MOS
- Series：*
- Mfr：Infineon Technologies
- Package：Tape & Reel (TR)
- FET Type：-
- Technology：-
- Drain to Source Voltage (Vdss)：-
- Current - Continuous Drain (Id) @ 25°C：-
- Drive Voltage (Max Rds On, Min Rds On)：-
- Rds On (Max) @ Id, Vgs：-
- Vgs(th) (Max) @ Id：-
- Gate Charge (Qg) (Max) @ Vgs：-
- Vgs (Max)：-
- Input Capacitance (Ciss) (Max) @ Vds：-
- FET Feature：-
- Power Dissipation (Max)：-
- Operating Temperature：-
- Grade：-
- Qualification：-
- Mounting Type：-
- Supplier Device Package：-
- Package / Case：-
Single FETs, MOSFETs datasheet and documents for BSC020N03LSGATMA2
Single FETs, MOSFETs Overview
The Infineon BSC020N03LSGATMA2 is an N-channel enhancement mode Power-MOSFET from the OptiMOS 3 series. It features a TDSON-8 surface-mount package with dimensions of 6.35mm x 5.35mm x 1.1mm. Key electrical parameters include a drain-source voltage (Vds) of 30V, a continuous drain current (Id) of 100A, and a maximum on-resistance (RDS(on)) of 2.9mΩ at VGS = 4.5V. The device has a typical gate charge (Qg) of 34nC, a maximum power dissipation (Pd) of 96W, and operates within a temperature range of -55°C to 150°C.
Single FETs, MOSFETs Feature Summary
- Optimized technology specifically designed for DC/DC converters and low-voltage applications such as notebooks and VGA power supplies.
- Fast switching characteristics suitable for high-frequency switch-mode power supplies (SMPS) with a low figure of merit for switching losses.
- Includes 100% avalanche testing to ensure robustness and reliability under transient conditions.
Single FETs, MOSFETs Applications
- High-power modules in industrial automation
- Process automation systems
- Point-of-load (POL) converters
Single FETs, MOSFETs Procurement Notes
Verify the specific ordering suffix to confirm the packaging format, as variations exist between cut tape and reel configurations. Ensure the component meets RoHS compliance requirements if mandated by your assembly standards. Cross-reference the datasheet revision date to confirm technical specifications align with your design constraints before finalizing procurement orders.
Single FETs, MOSFETs Selection Notes
Select this component for designs requiring low conduction losses in 30V environments. The TDSON-8 package offers a compact footprint suitable for space-constrained PCB layouts. Consider the thermal performance relative to the 96W dissipation rating when designing heat sinking solutions for high-current applications.
Single FETs, MOSFETs Part Context
This part belongs to Infineon's OptiMOS 3 family, which focuses on low-voltage power management. It serves as a surface-mount alternative to through-hole devices, providing improved thermal performance and automated assembly compatibility. The series is engineered to balance switching speed and conduction efficiency for modern power electronics.
Single FETs, MOSFETs Replacement Considerations
Direct substitutes may include other OptiMOS 3 variants with similar voltage and current ratings. Verify pinout compatibility and thermal resistance values when considering cross-brand replacements to ensure circuit integrity.
Explore related parts through FETs, MOSFETs, Transistors, Discrete Semiconductor Products, all product categories.
