Product Detailed Parameters
- Description：24BIT CLOCKLESS LINK TRAN
- Series：Clockless Link™
- Mfr：Rohm Semiconductor
- Package：Tape & Reel (TR),Cut Tape (CT)
- Function：Serializer
- Data Rate：1.63Gbps
- Input Type：LVCMOS
- Output Type：-
- Number of Inputs：24
- Number of Outputs：-
- Voltage - Supply：2.3V ~ 3.6V
- Operating Temperature：-40°C ~ 85°C
- Grade：Automotive
- Qualification：-
- Mounting Type：Surface Mount
- Package / Case：48-LQFP
- Supplier Device Package：48-VQFP (7x7)
Download product information
Overview
The BU17101AKV-ME2 is a serialiser within the Clockless Link series, manufactured by ROHM Semiconductor. It operates on a 2.3 V to 3.6 V supply voltage and supports a data rate of 1.63 Gbps. The device features 24 LVCMOS inputs and is housed in a 48-VQFP (7x7) package with SMD/SMT mounting style. It functions as a 24-bit clockless link transmitter, designed for automotive grade applications with an operating temperature range of -40°C to +85°C.
Feature Summary
- Supports high-speed serialisation at 1.63 Gbps for video or data transmission
- Integrates 24 LVCMOS input channels for parallel-to-serial conversion
- Designed for automotive environments with specified reliability standards
Applications
- Automotive display systems requiring high-bandwidth signal transmission
- In-vehicle infotainment interfaces
- Digital cockpit display drivers
Procurement Notes
Verify the specific suffix ME2 against the official datasheet to confirm pinout and electrical characteristics match the design requirements. Ensure the 48-VQFP footprint aligns with the PCB layout. Confirm automotive qualification status if required by the system specification before finalising component selection.
Selection Notes
Select this component when a compact serialiser with 24 parallel inputs is needed for automotive displays. The 1.63 Gbps speed suits standard resolution video links. Verify that the 2.3 V to 3.6 V supply range matches the system power rails. Consider the 48-VQFP package size constraints during mechanical design.
Part Context
This part belongs to the BU17101AKV family of clockless link transmitters. It is specifically engineered for automotive-grade reliability, distinguishing it from commercial-grade counterparts. The ME2 suffix typically denotes specific packaging or quality certifications defined by ROHM for automotive supply chains.
Replacement Considerations
Check for direct substitutes within the BU17101 series with different suffixes. Verify compatibility with existing deserialisers in the system. No other public substitute part numbers are confirmed.
