Product Detailed Parameters
- Description：DIODE SCHOTTKY 20V 1A DO213AB
- Series：-
- Mfr：Vishay General Semiconductor - Diodes Division
- Package：Tape & Reel (TR),Cut Tape (CT)
- Technology：Schottky
- Voltage - DC Reverse (Vr) (Max)：20 V
- Current - Average Rectified (Io)：1A
- Voltage - Forward (Vf) (Max) @ If：500 mV @ 1 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：-
- Current - Reverse Leakage @ Vr：500 µA @ 20 V
- Capacitance @ Vr, F：110pF @ 4V, 1MHz
- Mounting Type：Surface Mount
- Package / Case：DO-213AB, MELF
- Supplier Device Package：DO-213AB (GL41)
- Operating Temperature - Junction：-55°C ~ 125°C
- Grade：-
- Qualification：-
Download product information
Overview
The BYM13-20-E3/96 is a surface mount Schottky barrier rectifier manufactured by Vishay General Semiconductor. It features a GL41 (DO-213AB) MELF package and operates with a maximum average forward rectified current of 1.0 A and a peak forward surge current of 30 A. The device supports a maximum repetitive peak reverse voltage of 20 V and maintains a low maximum instantaneous forward voltage of 0.50 V at rated current. It is qualified to AEC-Q101 standards and meets MSL level 1 requirements.
Feature Summary
- Guardring structure provides enhanced overvoltage protection capabilities
- Low forward voltage drop design minimizes power losses and improves efficiency
- High surge current capability ensures robustness against transient loads
- Automated placement optimized for high-volume manufacturing processes
Applications
- Low voltage high frequency inverters
- Freewheeling circuits
- DC/DC converters
- Polarity protection applications
Procurement Notes
Verify the specific ordering suffix to confirm compliance status, as E3 indicates RoHS compliance while HE3 denotes automotive qualification. Confirm the delivery mode matches production needs, such as 7-inch or 13-inch tape and reel formats. Ensure technical parameters align with the target application's thermal and electrical requirements before finalizing procurement.
Selection Notes
Select this component for designs requiring low forward voltage drop and high efficiency in compact surface mount layouts. The DO-213AB package suits automated assembly lines. Verify that the 20 V reverse voltage rating accommodates circuit peaks and that the 1.0 A current capacity meets load demands under expected operating temperatures.
Part Context
This part belongs to the BYM13 series of surface mount Schottky barrier rectifiers from Vishay. It shares the GL41 package form factor with other variants in the lineup but differs in voltage ratings and specific electrical characteristics. The series is designed for general-purpose rectification in space-constrained electronic applications.
Replacement Considerations
Direct substitutes within the same series include BYM13-30, BYM13-40, BYM13-50, and BYM13-60, which offer higher reverse voltage ratings. Equivalent packages may include SGL41-20, though verification of specific electrical parameters is required.
FAQ
What does the polarity marking on the device indicate?
Two bands indicate the cathode end. The first band denotes the device type, and the second band denotes the voltage type.
Is the BYM13-20-E3/96 suitable for high-temperature environments?
Yes, it has an operating junction temperature range of -55 °C to +125 °C and meets MSL level 1 with a maximum peak reflow temperature of 250 °C.
