Product Detailed Parameters
- Description：DIODE STANDARD 600V 30A TO2472
- Series：-
- Mfr：WeEn Semiconductors
- Package：Tube
- Technology：Standard
- Voltage - DC Reverse (Vr) (Max)：600 V
- Current - Average Rectified (Io)：30A
- Voltage - Forward (Vf) (Max) @ If：1.55 V @ 30 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：75 ns
- Current - Reverse Leakage @ Vr：10 µA @ 600 V
- Capacitance @ Vr, F：-
- Mounting Type：Through Hole
- Package / Case：TO-247-2
- Supplier Device Package：TO-247-2
- Operating Temperature - Junction：175°C (Max)
- Grade：-
- Qualification：-
Download product information
Overview
The BYV30W-600PQ is a fast recovery rectifier manufactured by WeEn Semiconductors. It features a single configuration with a maximum repetitive peak reverse voltage of 600 V and an average forward current rating of 30 A. The device utilizes a TO-3PF-3 through-hole package. Key electrical parameters include a maximum forward voltage of 1.18 V, a maximum non-repetitive peak surge current of 330 A, and a reverse current of 2 uA. The component exhibits a reverse recovery time of 65 ns and supports a maximum operating temperature of +175 C.
Feature Summary
- Fast recovery rectifier technology designed for high-speed switching applications
- High thermal cycling performance capability
- Soft recovery characteristic to minimize power consuming oscillations
Applications
- Secondary rectification in power supplies
- General purpose switching circuits
- Home appliance power supply systems
Procurement Notes
Verify the exact part number against official manufacturer documentation, as datasheet references may vary between similar model designations within the same product family. Confirm RoHS compliance status and specific packaging details directly with the supplier or authorized distributor before finalizing procurement orders.
Selection Notes
Select this component for designs requiring robust high-voltage handling and efficient thermal management in through-hole assemblies. Ensure the circuit layout accommodates the physical dimensions of the TO-3PF-3 package and that the thermal resistance characteristics align with the system's heat dissipation requirements.
Part Context
This component belongs to the SABER series of ultrafast power diodes produced by WeEn Semiconductors. The series is engineered for high reliability and low on-state losses, making it suitable for demanding power electronics environments where efficiency and durability are critical operational factors.
Replacement Considerations
Cross-reference with other models in the BYV30W series or equivalent fast recovery rectifiers from other manufacturers. Verify pinout compatibility and ensure that substitute components meet or exceed the original specifications for voltage, current, and recovery time.
