Product Detailed Parameters
- Description：DIODE STANDARD 50V 8A ITO220AC
- Series：-
- Mfr：Vishay General Semiconductor - Diodes Division
- Package：Tube
- Technology：Standard
- Voltage - DC Reverse (Vr) (Max)：50 V
- Current - Average Rectified (Io)：8A
- Voltage - Forward (Vf) (Max) @ If：1.3 V @ 20 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：25 ns
- Current - Reverse Leakage @ Vr：10 µA @ 50 V
- Capacitance @ Vr, F：-
- Mounting Type：Through Hole
- Package / Case：TO-220-2 Full Pack, Isolated Tab
- Supplier Device Package：ITO-220AC
- Operating Temperature - Junction：-65°C ~ 150°C
- Grade：-
- Qualification：-
Download product information
Overview
The BYWF29-50HE3_A/P is a standard single diode manufactured by Vishay General Semiconductor - Diodes Division. It features a maximum DC reverse voltage (Vr) of 50 V and an average rectified current (Io) of 8 A. The component utilizes the TO-220AC package for through-hole mounting. It is part of the FES series and employs standard technology with a glass passivated pellet chip junction.
Feature Summary
- Glass passivated pellet chip junction
- Ultrafast recovery time
- Low switching losses
- High efficiency operation
Applications
- General purpose power applications
- Inverter circuits
- Free-wheeling diodes
- Flyback diodes
Procurement Notes
Verify the specific suffix against official documentation to confirm exact electrical characteristics and packaging configuration. Ensure the ordering code matches the required voltage and current ratings for the target circuit design. Cross-reference the manufacturer's latest datasheet to validate compliance with RoHS directives and other regulatory standards applicable to the deployment region.
Selection Notes
Select this component for applications requiring robust through-hole mounting and high current handling capabilities. The 50 V rating suits low-voltage AC/DC conversion systems. Evaluate thermal management requirements based on the TO-220AC package's heat dissipation properties. Confirm that the ultrafast recovery characteristics align with the switching frequency demands of the specific power supply topology.
Part Context
This device belongs to the BYWF29 series of fast recovery rectifiers from Vishay. These components are engineered for high-efficiency power conversion. The series offers various voltage ratings to accommodate different circuit requirements while maintaining consistent current handling and package form factors for standardized PCB layouts.
Replacement Considerations
Check for direct substitutes such as BYWF29-100HE3_A/P or BYWF29-200HE3_A/P if higher voltage ratings are acceptable. Verify pinout compatibility and thermal performance before substituting with generic equivalents.
