CDBKA20120L-HF

$1.28

Description：DIODE ARR SCHOTT 120V 10A TO-262
Series：-

SKU:e2155928405a Category: Diode Arrays Brand: Comchip Technology

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CDBKA20120L-HF is listed in the Diode Arrays range at ChipApex. The manufacturer field lists Comchip Technology. Its product description is DIODE ARR SCHOTT 120V 10A TO-262. Review the specifications below when checking this part for your BOM.

Diode Arrays specifications for CDBKA20120L-HF

Description：DIODE ARR SCHOTT 120V 10A TO-262
Series：-
Mfr：Comchip Technology
Package：Tube
Diode Configuration：1 Pair Common Cathode
Technology：Schottky
Voltage - DC Reverse (Vr) (Max)：120 V
Current - Average Rectified (Io) (per Diode)：10A
Voltage - Forward (Vf) (Max) @ If：800 mV @ 10 A
Speed：Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：50 µA @ 120 V
Operating Temperature - Junction：-55°C ~ 150°C
Mounting Type：Through Hole
Package / Case：TO-262-3 Long Leads, I2PAK, TO-262AA
Supplier Device Package：TO-262
Grade：-
Qualification：-
