CM200DU-12NFH

Overview

The CM200DU-12NFH is a six-element insulated gate bipolar transistor (IGBT) module manufactured by Powerex Inc. It features an N-channel configuration with a maximum collector-emitter voltage of 1200 V and a continuous collector current rating of 200 A. The device utilizes a MODULE-20 flange mount package with 20 terminals and an isolated case connection. Designed for high-power applications, it supports operation up to a maximum junction temperature of 150 °C and complies with RoHS standards.

Feature Summary

• Six-element bridge configuration with built-in diodes for complete power conversion stages
• Isolated flange mount design facilitating efficient thermal management
• High-voltage capability suitable for demanding industrial power electronics

Applications

• Industrial motor drives and AC servo systems
• Uninterruptible power supplies (UPS)
• Wind energy conversion systems
• High-power welding equipment

Procurement Notes

Verify the manufacturer part number against official Powerex documentation to ensure authenticity. Confirm that the specific suffix matches the required electrical characteristics and pinout configuration. Check for RoHS compliance status if environmental regulations apply to the end product. Ensure the component is sourced from authorized distributors to avoid counterfeit risks.

Selection Notes

Select this module for applications requiring a 1200 V rating and 200 A current capacity in a compact form factor. Evaluate the thermal resistance of the MODULE-20 package against the system's cooling capabilities. Consider the switching speed and forward voltage drop relative to overall system efficiency requirements. Ensure the drive circuitry is compatible with the IGBT gate specifications.

Part Context

This component belongs to the CM200DU series of six-unit IGBT modules produced by Powerex. These modules are engineered for robust performance in high-power density applications. The DU series typically integrates anti-parallel diodes with the IGBTs, providing a complete solution for inverter bridges without requiring external freewheeling components.

Replacement Considerations

Direct replacements must match the 1200V/200A rating and MODULE-20 footprint. Verify pin compatibility and thermal interface dimensions before substitution.
