CR16MCS9VJE7/NOPB

$16.76

Description：IC MCU 16BIT 64KB FLASH 80MQFP
Series：CompactRISC™
Mfr：Texas Instruments
Package：Tray
Core Processor：CR16B

SKU:519ae8188112 Category: Microcontrollers Brand: Texas Instruments

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC MCU 16BIT 64KB FLASH 80MQFP
Series：CompactRISC™
Mfr：Texas Instruments
Package：Tray
Core Processor：CR16B
Core Size：16-Bit
Speed：16MHz
Connectivity：ACCESS.Bus (2-Wire/I2C, SMBus), CANbus, Microwire/Plus (SPI), UART/USART
Peripherals：POR, PWM, WDT
Number of I/O：56
Program Memory Size：64KB (64K x 8)
Program Memory Type：FLASH
EEPROM Size：2K x 8
RAM Size：3K x 8
Voltage - Supply (Vcc/Vdd)：4.5V ~ 5.5V
Data Converters：A/D 8x12b
Oscillator Type：External
Operating Temperature：-40°C ~ 125°C (TA)
Mounting Type：Surface Mount
Supplier Device Package：80-QFP (14x14)
Package / Case：80-QFP
Grade：-
Qualification：-

Download product information

CR16MCS9VJE7/NOPB

Overview

The CR16MCS9VJE7/NOPB is a 16-bit microcontroller from the CompactRISC series, manufactured by Texas Instruments. It features a CR16B core processor with a maximum speed of 16MHz. The device includes 64KB (64K x 8) of FLASH program memory, 2K x 8 EEPROM, and 3K x 8 RAM. It operates within a supply voltage range of 4.5V to 5.5V and supports an operating temperature range of -40°C to 125°C. Connectivity options include ACCESS.Bus, CANbus, Microwire/Plus (SPI), and UART/USART interfaces. The unit is housed in an 80-QFP package with 56 I/O lines and integrates peripherals such as POR, PWM, and WDT.

Feature Summary

Integrates a 16-bit RISC architecture for efficient instruction processing
Provides non-volatile storage via integrated FLASH and EEPROM memory
Supports multiple communication protocols including CANbus and SPI
Includes built-in power-on reset, pulse-width modulation, and watchdog timer

Applications

Industrial control systems requiring robust communication interfaces
Automotive embedded applications utilizing CANbus connectivity
Consumer electronics needing high-speed data processing
General-purpose microcontroller solutions for embedded logic

Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS3 compliance status and check for moisture sensitivity level handling requirements during storage and assembly. Ensure the specific suffix matches design specifications as obsolete status may affect long-term availability.

Selection Notes

Select this component when a 16-bit architecture with extensive I/O capabilities is required. Consider the 80-pin QFP package constraints for PCB layout. Evaluate the need for CANbus and SPI interfaces against alternative simpler MCUs if cost reduction is prioritized over feature set.

Part Context

This part belongs to the CR16MCS9 family of 16-bit microcontrollers. It utilizes the CompactRISC technology designed for performance and code efficiency. The NOPB suffix indicates lead-free construction compliant with environmental standards. It serves as a mid-range solution within Texas Instruments' embedded controller portfolio.
