D3001N68TXPSA1

$1,412.91

Description：DIODE STANDARD 6800V 3910A
Series：-
Mfr：Infineon Technologies
Package：Tray

SKU:f484b2836bf0 Category: Single Diodes Brand: Infineon Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

D3001N68TXPSA1 is listed in the Single Diodes range at ChipApex. The manufacturer field lists Infineon Technologies. Its product description is DIODE STANDARD 6800V 3910A. Review the specifications below when checking this part for your BOM.

Single Diodes specifications for D3001N68TXPSA1

Description：DIODE STANDARD 6800V 3910A
Series：-
Mfr：Infineon Technologies
Package：Tray
Technology：Standard
Voltage - DC Reverse (Vr) (Max)：6800 V
Current - Average Rectified (Io)：3910A
Voltage - Forward (Vf) (Max) @ If：1.7 V @ 4000 A
Speed：Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：100 mA @ 6800 V
Capacitance @ Vr, F：-
Mounting Type：Chassis Mount
Package / Case：DO-200AE
Supplier Device Package：-
Operating Temperature - Junction：-40°C ~ 160°C
Grade：-
Qualification：-

Single Diodes datasheet and documents for D3001N68TXPSA1

D3001N68TXPSA1

Single Diodes Overview

The D3001N68TXPSA1 is a standard recovery rectifier manufactured by Infineon Technologies. It features a single configuration with a maximum repetitive reverse voltage of 6.8 kV and an average forward current rating of 3.84 kA. The device exhibits a maximum forward voltage drop of 1.7 V and a maximum non-repetitive surge current capability of 57 kA. Reverse leakage current is specified at 100 mA. Operating temperature ranges from -40°C to +160°C. The component utilizes press-fit installation within the D-12035K package.

Single Diodes Feature Summary

High-voltage rectification capability up to 6.8 kV
Robust surge current handling rated at 57 kA
Press-fit mounting technology for secure connection

Single Diodes Applications

Industrial power conversion systems
High-voltage DC transmission equipment
Heavy-duty rectifier bridges

Single Diodes Procurement Notes

Verify the exact part number suffix against official Infineon documentation to confirm mechanical and electrical specifications. Ensure compatibility with existing press-fit tooling and thermal management requirements. Confirm RoHS compliance status through the manufacturer's product compliance database before integration into regulated assemblies.

Single Diodes Selection Notes

Select this component for applications requiring high voltage isolation and substantial continuous current capacity. Evaluate thermal dissipation needs given the 1.7 V forward voltage drop at high currents. Verify that the system design accommodates the specific D-12035K package dimensions and press-fit force requirements for reliable long-term operation.

Single Diodes Part Context

This rectifier belongs to Infineon's high-power diode portfolio designed for demanding industrial environments. The D3001 series provides robust performance in heavy-duty power electronics. The XPSA1 suffix denotes specific packaging or testing variations within the standard D3001N68T family line.
