DCA200DB80

Overview

The DCA200DB80 is a silicon diode module manufactured by SanRex Corporation. It features a single pair series connection configuration designed for high-power applications. The component is rated for a maximum reverse voltage of 800V and supports a forward current of 200A. It utilizes a chassis mount installation style to facilitate thermal management in industrial environments.

Feature Summary

• Single pair series connection configuration
• Chassis mount design for robust integration

Applications

• Industrial power conversion systems
• Motor control applications
• General rectification circuits

Procurement Notes

Verify the specific datasheet version with the manufacturer or authorized distributor before procurement. Confirm that the chassis mounting requirements align with your system's mechanical constraints. Ensure thermal interface materials are compatible with the module's operating temperature range to maintain performance reliability.

Selection Notes

Select this module when a 800V reverse voltage rating and 200A forward current capacity are required. The series configuration suits applications needing specific voltage handling within a single package. Consider the chassis mount style for efficient heat dissipation compared to other packaging types.

Part Context

This component belongs to the SanRex diode array product line. It is categorized under discrete semiconductor modules. The module is constructed using silicon technology, which is standard for high-voltage power electronics. It serves as a key element in converting AC to DC power in heavy-duty equipment.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing designs if considering alternative manufacturers. Check electrical ratings and physical dimensions carefully before substitution.
