DDB6U180N16RRPB11BPSA1

Overview

The Infineon DDB6U180N16RRPB11BPSA1 is an EconoPACK2 IGBT module featuring Trench/Fieldstop IGBT4 and Emitter Controlled 4 diode technology with PressFIT connection. It integrates a rectifier, inverter, and brake chopper. The rectifier supports a repetitive peak reverse voltage of 1600 V and a maximum RMS current of 180 A at TC = 80°C. The brake chopper IGBT provides a collector-emitter voltage of 1200 V and a continuous DC collector current of 100 A at TC = 80°C. The module utilizes an Al2O3 substrate for low thermal resistance and includes an isolated copper baseplate.

Feature Summary

• Integrates Trench/Fieldstop IGBT4 and Emitter Controlled 4 diode technologies within a single compact package.
• Utilizes PressFIT contact technology to eliminate wire bonding and improve mechanical robustness.
• Features an isolated copper baseplate with an Al2O3 substrate for high power density and efficient heat dissipation.
• Includes an integrated brake chopper circuit alongside the main inverter and rectifier stages.

Applications

• Auxiliary inverters
• Air conditioning systems
• Motor drives
• Servo drives

Procurement Notes

Verify the specific ordering suffix BPSA1 against official Infineon documentation to confirm exact manufacturing specifications and compliance status. Ensure that the PressFIT termination method aligns with the target PCB design requirements. Confirm RoHS compliance details through the manufacturer's certificate of conformity prior to final procurement authorization.

Selection Notes

Select this module for applications requiring high power density and reliable press-fit connections. Evaluate the thermal resistance values from the datasheet to ensure adequate heatsinking for the intended operating temperature range. Consider the short-circuit withstand capability and switching losses when designing the gate drive circuitry and protection mechanisms for the system.

Part Context

This component belongs to the Infineon EconoPACK2 product family, which is designed for high-performance power conversion. The series combines advanced IGBT4 and Emitter Controlled 4 diode technologies to optimize switching performance and conduction losses. The packaging standardizes mounting dimensions while providing robust electrical isolation and thermal management capabilities for industrial power electronics.

Replacement Considerations

DDB6U180N16RR_B11
