ECS-2532HS-540-3-G

Oscillators Overview

The ECS-2532HS-540-3-G is a standard clock oscillator manufactured by ECS Inc. It operates at a frequency of 54 MHz and utilizes CMOS output logic. The device functions with a supply voltage of 3.3 V and features enable/disable control capabilities. It is housed in a compact 4-SMD, no-lead package suitable for surface mount applications. The unit supports an operating temperature range from -40°C to +85°C and draws a current of 10 mA.

Oscillators Feature Summary

• CMOS output interface
• Enable/disable functionality
• Automotive-grade reliability

Oscillators Applications

• Standard clock generation
• Miniature SMD devices
• Frequency control systems

Oscillators Procurement Notes

Verify the specific package configuration against official documentation, as sources indicate conflicting information regarding lead counts. Confirm that the 3.3V supply requirement aligns with system design constraints. Ensure the operating temperature range meets environmental specifications for the intended application environment before finalizing procurement decisions.

Oscillators Selection Notes

Select this component when a 54 MHz CMOS clock signal is required in a small form factor. The automotive-grade classification suggests suitability for demanding environments. Consider the enable pin functionality if power management or clock gating is necessary within the circuit design architecture.

Oscillators Part Context

This part belongs to the ECS-2532HS series of standard clock oscillators. These devices are designed as miniature surface-mount solutions offering frequencies up to 200 MHz. The series emphasizes stability and low power consumption for modern electronic applications requiring precise timing references.

Oscillators Replacement Considerations

Direct substitutes require matching the 54 MHz frequency, 3.3V CMOS output, and compatible package dimensions. Verify thermal characteristics and enable pin configurations to ensure functional equivalence in existing designs.
