EP2AGX45DF29I3

Field Programmable Gate Array Overview

The EP2AGX45DF29I3 is an Arria II GX field-programmable gate array manufactured by Altera. It features 42,959 logic elements and 18,050 adaptive logic modules within a 780-ball FBGA package. The device includes 3.35 Mbit of embedded memory and supports up to 364 I/Os. It operates with core voltages between 870 mV and 930 mV and supports data rates of 1.25 Gb/s via eight transceivers. The industrial temperature range spans from -40°C to +100°C.

Field Programmable Gate Array Feature Summary

• Integrates eight high-speed serial transceivers for parallel interface applications
• Provides extensive programmable logic resources through adaptive logic modules
• Supports low-voltage operation for optimized power efficiency

Field Programmable Gate Array Applications

• High-speed serial communication interfaces
• Parallel-to-serial conversion systems
• Industrial control processing units

Field Programmable Gate Array Procurement Notes

Verify the specific suffix designation against official datasheets, as standard commercial listings often use 'I3N' or 'I3G'. Confirm end-of-life status with the manufacturer before design finalization. Ensure compatibility with required PCB footprint dimensions for the 780-ball FBGA package during procurement planning.

Field Programmable Gate Array Selection Notes

Select this model when requiring moderate logic density with integrated serial connectivity. Compare total embedded memory requirements against the 3.35 Mbit limit. Verify that the 364 I/O count meets system interface needs without excessive pin multiplexing constraints.

Field Programmable Gate Array Part Context

This component belongs to the Arria II GX family, designed for cost-sensitive applications requiring Gigabit Ethernet and PCIe connectivity. It bridges the gap between lower-density Cyclone devices and higher-end Stratix families, offering balanced performance for mid-range signal processing tasks.

Field Programmable Gate Array Replacement Considerations

Check for updated Arria V or Agilex series equivalents if long-term supply is required. Verify pinout compatibility if substituting within the same Arria II family.
