F4100R17ME4B11BPSA2

$157.54

Description：MEDIUM POWER ECONO AG-ECONOD-311
Series：EconoDUAL™ 3

SKU:668f24faf568 Category: IGBT Modules Brand: Infineon Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MEDIUM POWER ECONO AG-ECONOD-311
Series：EconoDUAL™ 3
Mfr：Infineon Technologies
Package：Tray
IGBT Type：Trench Field Stop
Configuration：Full Bridge Inverter
Vce(on) (Max) @ Vge, Ic：2.3V @ 15V, 100A
Input：Standard
NTC Thermistor：No
Operating Temperature：-40°C ~ 150°C (TJ)
Mounting Type：Chassis Mount
Package / Case：Module
Supplier Device Package：AG-ECONOD-6
Voltage - Collector Emitter Breakdown (Max)：1700 V
Current - Collector (Ic) (Max)：155 A
Power - Max：-
Current - Collector Cutoff (Max)：3 mA
Input Capacitance (Cies) @ Vce：9 nF @ 25 V

Download product information

F4100R17ME4B11BPSA2

Overview

The F4100R17ME4B11BPSA2 is a silicon IGBT module from Infineon Technologies, belonging to the EconoDUAL 3 series. It features a trench field-stop technology and a full-bridge inverter configuration. The device supports a maximum collector-emitter voltage of 1700 V and a continuous collector current of 155 A at 25°C. The saturation voltage is specified as 2.3 V under standard test conditions. Operating temperatures range from -40°C to +150°C junction temperature. The component utilizes a baseplate mounting style within a module package.

Feature Summary

Trench field-stop IGBT technology for optimized switching performance
Full-bridge inverter configuration integrating four switches
EconoDUAL 3 packaging designed for efficient thermal management

Applications

Industrial motor drives
Uninterruptible power supplies
Induction heating systems

Procurement Notes

Verify part authenticity through authorized channels. Confirm RoHS compliance status via official documentation. Check for specific ordering suffix variations that may indicate minor revisions. Ensure compatibility with existing thermal interface materials. Validate supply chain sources against manufacturer lists.

Selection Notes

Compare collector current ratings against peak load requirements. Evaluate thermal resistance characteristics for heatsink design. Consider gate drive voltage compatibility with control circuits. Assess switching frequency limitations based on application needs. Review mechanical dimensions for PCB layout integration.

Part Context

This component is part of Infineon's EconoDUAL 3 family, which provides standardized form factors for power electronics. It succeeds earlier generations like the EconoPACK series, offering improved thermal performance and compact design. The model shares architectural similarities with other F41xxR17 variants but differs in current handling capabilities.

Replacement Considerations

Direct substitutes include F4100R17ME4B11BPSA1, which represents an earlier revision of the same functional specification. Cross-reference pinouts and thermal characteristics when transitioning between revisions. Verify if updated versions offer enhanced reliability or modified electrical parameters.
