FDMC86102LZ

Single FETs, MOSFETs Overview

The onsemi FDMC86102LZ is a single N-channel PowerTrench MOSFET designed for surface-mount applications. It features a drain-source voltage (Vdss) of 100 V and an enhancement mode channel configuration. The device supports a continuous drain current of 7 A at ambient temperature and 18 A at case temperature. Key electrical parameters include a maximum gate-source voltage of ±20 V, a typical gate charge of 22 nC at 10 V, and a maximum on-resistance of 24 mΩ at 6.5 A with 10 V gate drive. It operates within a junction temperature range of -55°C to +150°C and is housed in an 8-MLP (3.3x3.3 mm) package.

Single FETs, MOSFETs Feature Summary

• PowerTrench technology provides low on-resistance for efficient power switching.
• Enhanced thermal performance allows high current handling in compact packages.
• Robust avalanche energy rating supports rugged operation in inductive loads.

Single FETs, MOSFETs Applications

• DC-DC converter circuits
• Motor control systems
• Load switch applications

Single FETs, MOSFETs Procurement Notes

Verify the specific suffix against official datasheets to confirm package type and tape/reel specifications. Ensure compatibility with RoHS and REACH compliance requirements for your region. Cross-reference the manufacturer part number with authorized distributors to avoid counterfeit components. Confirm lead times and packaging quantities directly with the supplier before finalizing orders.

Single FETs, MOSFETs Selection Notes

Select this component when a 100 V N-channel MOSFET with low Rds(on) is required in a small footprint. Compare the 24 mΩ on-resistance against system efficiency targets. Evaluate the 8-MLP package dimensions against PCB space constraints. Consider the thermal dissipation capabilities relative to the expected operating current and ambient conditions.

Single FETs, MOSFETs Part Context

This part belongs to the PowerTrench series from onsemi, which utilizes advanced trench gate technology. The series is engineered for high-density power management solutions. The FDMC86102LZ variant specifically targets applications requiring robust performance in minimal board space.

Single FETs, MOSFETs Replacement Considerations

Check for direct substitutes such as FDMC86102 or FDMC86102L if pinout and electrical characteristics match. Verify that alternative parts meet the same 100 V and current ratings. Ensure thermal resistance values are comparable to maintain system reliability.
