Product Detailed Parameters
- Description：EQUALIZER 2.92MM 18-40 GHZ 6 DB
- Series：-
- Mfr：Fairview Microwave
- Package：Bag
- Function：Linear Equalizer
- Frequency：18GHz ~ 40GHz
- RF Type：General Purpose
- Secondary Attributes：SMA Connectors
- Mounting Type：Chassis Mount
- Package / Case：2.92mm In-Line Module
- Supplier Device Package：-
- Grade：-
- Qualification：-
Download product information
Overview
The FMAT9016 is a linear equalizer manufactured by Fairview Microwave, designed for high-frequency signal conditioning. It operates within a frequency range of 18 GHz to 40 GHz. This component functions as a specialized cable assembly intended to maintain signal integrity across its specified bandwidth. The unit is packaged individually in a bag and bears the Fairview Microwave trademark. It belongs to the category of RF cable assemblies and is classified under general miscellaneous components in distributor catalogs.
Feature Summary
- Provides linear equalization capabilities for signal paths
- Operates effectively within the 18 GHz to 40 GHz frequency spectrum
Applications
- High-frequency signal conditioning
- RF system integration
- Test and measurement equipment
Procurement Notes
Verify the specific model number FMAT9016 against official Fairview Microwave documentation to confirm the 18-40 GHz operational range. Ensure compatibility with existing RF infrastructure before procurement. Check current availability status through authorized distributors, as supply may be restricted. Confirm packaging details match the required quantity for your project needs.
Selection Notes
Select this component when linear equalization is required for frequencies between 18 GHz and 40 GHz. Consider the physical dimensions and connector types if not explicitly detailed in the summary. Evaluate the need for a dedicated equalizer versus other signal management solutions based on system loss characteristics. Verify that the operating environment supports the specified frequency range.
Part Context
This part is categorized as an RF cable assembly and falls under the broader class of miscellaneous electronic components. It is distinct from passive filters or active amplifiers, serving specifically as a gain equalizer. The product line includes similar models like the FMAT9022, indicating a family of frequency-specific equalization solutions offered by the manufacturer.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided source data. Consult Fairview Microwave technical support for direct equivalents or cross-references. Do not assume generic equalizers are compatible due to potential differences in insertion loss and return specifications.
