FMAT9035

Overview

The FMAT9035 is a high-power RF amplifier module manufactured by Fairview Microwave. It operates within a frequency range of 820 MHz to 960 MHz, providing a gain of 17 dB. The device delivers an output power of 30 dBm at the 1 dB compression point (P1dB) and features a noise figure of 2 dB. It requires a supply voltage between 8 V and 12 V with a current draw of 500 mA. The unit utilizes SMA connectors and is designed for base mounting in a module package.

Feature Summary

• Provides linear amplification across the 820 MHz to 960 MHz band
• Delivers high output power capability suitable for demanding RF applications
• Incorporates low noise characteristics for signal integrity preservation
• Features robust construction with base-mount installation options

Applications

• Wireless communication infrastructure systems
• Test and measurement equipment signal generation
• Industrial radio frequency heating and processing

Procurement Notes

Verify the specific ordering suffix and connector type compatibility before purchase. Confirm that the required supply voltage and current specifications align with the system power design. Ensure mechanical clearance is available for the base-mounted module form factor. Check for any regional distribution restrictions or lead time variations associated with this component.

Selection Notes

Select this model when operation within the 820-960 MHz range is required. Consider the 17 dB gain and 30 dBm output power for link budget calculations. Evaluate the 2 dB noise figure against system sensitivity requirements. Verify that the SMA interface and base-mount style fit the physical enclosure constraints.

Part Context

This component belongs to the Fairview Microwave RF amplifier portfolio, specifically designed for general-purpose applications. It serves as a discrete solution for signal boosting in wireless and industrial sectors. The module integrates GaAs technology to achieve performance metrics within its specified frequency band.

Replacement Considerations

No public confirmed substitute part numbers are documented.
