FMBT1647

$724.98

Description：BIAS TEE TYPE F 10MHZ-3GHZ
Series：-
Mfr：Fairview Microwave
Package：Bag

SKU:464ec1539d01 Category: RF Misc ICs and Modules Brand: Fairview Microwave

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：BIAS TEE TYPE F 10MHZ-3GHZ
Series：-
Mfr：Fairview Microwave
Package：Bag
Function：Bias Tee
Frequency：10MHz ~ 3GHz
RF Type：General Purpose
Secondary Attributes：100V Supply
Mounting Type：Chassis Mount
Package / Case：Module
Supplier Device Package：Module
Grade：-
Qualification：-

Download product information

FMBT1647

Overview

The Fairview Microwave FMBT1647 is a Type F bias tee adapter designed for RF applications. It operates within a frequency range of 10 MHz to 3 GHz and features a 75 Ohm impedance. The device supports a DC supply voltage up to 100 Volts and handles a maximum current rating of 2.5 Amps. Constructed for chassis mounting, it integrates RF and DC signal paths into a single compact module.

Feature Summary

Integrates RF and DC signals via a dedicated bias tee topology
Supports high-voltage DC injection up to 100 Volts
Designed for robust chassis mounting installation

Applications

RF test and measurement instrumentation requiring combined signal and power delivery
Active antenna systems utilizing 75 Ohm coaxial infrastructure
Broadband communication equipment integrating DC bias with RF transmission

Procurement Notes

Verify the specific DC voltage and current requirements against the 100V and 2.5A limits before procurement. Confirm that the system impedance matches the 75 Ohm specification to prevent signal reflection. Ensure the operating frequency remains within the 10 MHz to 3 GHz range for optimal performance. Check for chassis mounting compatibility in the target enclosure design.

Selection Notes

Select this component when a 75 Ohm interface is required for both RF and DC paths. It is suitable for applications needing up to 100V DC bias within the specified frequency band. Consider the chassis mount form factor for fixed installations rather than flexible cable assemblies. Compare against 50 Ohm alternatives if the system impedance differs.

Part Context

This part belongs to the Fairview Microwave RF adapters and bias tee category. It serves as a specialized interconnect solution combining signal routing with power injection. The Type F connector standard ensures compatibility with common broadcast and cable television infrastructure components.
