FMFD7000

Overview

The FMFD7000 is an RF frequency divider module manufactured by Fairview Microwave. It operates as a divide-by-7 prescaler with SMA connectors. The device functions within a general-purpose range of 14.2 MHz to 2.142 GHz and supports frequencies from 100 MHz to 15 GHz. It complies with RoHS standards.

Feature Summary

• Provides divide-by-7 frequency division functionality
• Integrates SMA connector interfaces for signal input and output
• Designed as a general-purpose RF integrated circuit module

Applications

• RF signal processing systems requiring frequency reduction
• Frequency synthesis circuits utilizing prescaler stages
• Test and measurement equipment operating in microwave ranges

Procurement Notes

Verify the specific SMA connector gender and pin configuration against system requirements before integration. Confirm that the operational frequency range aligns with the target application spectrum. Ensure compliance with environmental regulations such as RoHS if required by the project specifications.

Selection Notes

Select this component when a fixed divide-by-7 ratio is necessary for frequency down-conversion. Consider the SMA interface compatibility with existing board layouts. Evaluate the power handling capabilities relative to the system's signal levels to ensure reliable operation within the specified frequency bands.

Part Context

Fairview Microwave specializes in high-quality RF and microwave components, including attenuators, adapters, and integrated modules. The FMFD7000 belongs to their portfolio of RF IC modules designed for precise signal conditioning and frequency manipulation in professional electronic applications.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
