Product Detailed Parameters
- Description：SYNTHESIZER SMA 1GHZ-6.4GHZ
- Series：-
- Mfr：Fairview Microwave
- Package：Bag
- Function：Synthesizer
- Frequency：1GHz ~ 6.4GHz
- RF Type：Radar
- Secondary Attributes：SMA Connectors
- Mounting Type：Chassis Mount
- Package / Case：Module, SMA Connectors
- Supplier Device Package：Module
- Grade：-
- Qualification：-
Download product information
Overview
The FMSN3909 is a frequency synthesizer module manufactured by Fairview Microwave, designed for RF applications within the 1 GHz to 6.4 GHz range. It features an integrated PLL synthesizer architecture with SMA connectors and delivers a typical output power of +15 dBm. The device supports a fine frequency resolution of 20 Hz steps, enabling precise signal generation capabilities suitable for radar and communication systems requiring stable spectral performance.
Feature Summary
- Integrated phase-locked loop (PLL) synthesizer architecture
- SMA connector interface for direct integration
- High-resolution frequency stepping capability
Applications
- Radar system signal generation
- RF test and measurement equipment
- Communication system local oscillators
Procurement Notes
Verify component authenticity through authorized distribution channels or official manufacturer documentation. Confirm that the received unit matches the specific part number designation and packaging details provided in the original datasheet. Ensure storage conditions comply with manufacturer guidelines to maintain operational integrity prior to installation.
Selection Notes
Select this module when a compact solution is required for generating signals between 1 GHz and 6.4 GHz with high spectral purity. The fixed +15 dBm output power and 20 Hz step resolution make it suitable for applications demanding precise frequency control without external tuning components.
Part Context
This component belongs to Fairview Microwave's portfolio of RF semiconductors and modules. It represents a specialized integrated solution for frequency synthesis, distinct from passive cable assemblies or discrete amplifiers offered by the same manufacturer. The module format simplifies design-in processes for engineers requiring turnkey frequency sources.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Users should consult the manufacturer directly for obsolescence management or equivalent replacement recommendations.
