Product Detailed Parameters
- Description：WG TERMINATION WR-229 3.22-4.9 G
- Series：-
- Mfr：Fairview Microwave
- Package：Bag
- Function：Termination
- Frequency：3.22GHz ~ 4.9GHz
- RF Type：Radar
- Secondary Attributes：5W
- Mounting Type：Chassis Mount
- Package / Case：Module
- Supplier Device Package：-
- Grade：-
- Qualification：-
Download product information
Overview
The FMW229TR1001 is a precision waveguide termination manufactured by Fairview Microwave, designed for radar applications within the WR-90 waveguide system. It operates effectively across a frequency range of 3.22 GHz to 4.9 GHz and supports an average power handling capacity of 5 Watts. The unit features an aluminum construction with a CPR-229F flange interface, ensuring secure mechanical connection and reliable RF performance in high-frequency environments.
Feature Summary
- Precision waveguide termination engineered for radar signal absorption
- Compatible with standard WR-90 waveguide dimensions and CPR-229F flanges
- Robust aluminum body construction for thermal stability and durability
Applications
- Radar system load termination
- Waveguide test setup calibration
- Microwave circuit impedance matching
Procurement Notes
Verify that the receiving equipment utilizes a CPR-229F flange interface to ensure mechanical compatibility. Confirm that the operational average power does not exceed 5 Watts to prevent component damage. Check datasheet specifications for VSWR requirements relevant to specific radar or measurement applications before integration.
Selection Notes
Select this model when a fixed load is required for WR-90 waveguide systems operating between 3.22 GHz and 4.9 GHz. Ensure the application demands a 5-watt average power rating. Consider the aluminum material properties for thermal management needs in continuous wave operations.
Part Context
This component belongs to Fairview Microwave's line of RF microwave and mmWave interconnect accessories. It serves as a passive termination device within the broader category of waveguide components, providing essential signal absorption capabilities for testing and system stabilization in radar and communication infrastructure.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Users must verify exact dimensional and electrical compatibility if considering alternative manufacturers or different model series from Fairview Microwave.
