FP35R12N2T7BPSA1

$62.47

Description：LOW POWER ECONO AG-ECONO2B-711
Series：EconoPIM™ 2

SKU:824afe332dff Category: IGBT Modules Brand: Infineon Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LOW POWER ECONO AG-ECONO2B-711
Series：EconoPIM™ 2
Mfr：Infineon Technologies
Package：Tray
IGBT Type：Trench Field Stop
Configuration：Three Phase Inverter
Vce(on) (Max) @ Vge, Ic：1.6V @ 15V, 35A
Input：Three Phase Bridge Rectifier
NTC Thermistor：Yes
Operating Temperature：-40°C ~ 175°C (TJ)
Mounting Type：Chassis Mount
Package / Case：Module
Supplier Device Package：AG-ECONO2B
Voltage - Collector Emitter Breakdown (Max)：1200 V
Current - Collector (Ic) (Max)：35 A
Power - Max：-
Current - Collector Cutoff (Max)：7 µA
Input Capacitance (Cies) @ Vce：6.62 nF @ 25 V

Download product information

FP35R12N2T7BPSA1

Overview

The FP35R12N2T7BPSA1 is a PIM IGBT module from Infineon Technologies, utilizing TRENCHSTOP™ IGBT7 technology. It features a 1200 V collector-emitter voltage and a nominal continuous DC collector current of 35 A at 25°C. The module integrates an NTC thermistor with a rated resistance of 5 kΩ at 25°C. Electrical characteristics include a typical collector-emitter saturation voltage of 1.60 V at 25°C and a forward voltage of 1.72 V for the inverter diode. The device operates within a junction temperature range of -40°C to +175°C.

Feature Summary

Integrates TRENCHSTOP™ IGBT7 and Emitter Controlled 7 diodes for optimized switching performance.
Includes an integrated NTC temperature sensor for precise thermal monitoring.
Constructed with a copper base plate and Al2O3 substrate to ensure high power cycling capability.
Utilizes solder contact technology for reliable mechanical and electrical connections.

Applications

Auxiliary inverters
Motor drives
Servo drives

Procurement Notes

Verify the specific ordering suffix BPSA1 against official documentation to confirm exact configuration details. Ensure compliance with industrial qualification standards such as IEC 60747 and IEC 60068 before integration. Confirm that the component meets all relevant safety and insulation requirements for the intended deployment environment.

Selection Notes

Select this module for applications requiring robust thermal cycling capability and low saturation voltage. Consider the 1200 V rating and 35 A current capacity when designing power stages. Evaluate the integrated NTC functionality if active thermal management is required. Verify compatibility with existing heatsinking solutions due to the EconoPIM™2 package dimensions.

Part Context

This component belongs to the EconoPIM™2 series, designed for three-phase input rectifier and inverter configurations. It represents Infineon's TRENCHSTOP™ IGBT7 generation, offering improved efficiency compared to previous technologies. The module is specifically qualified for industrial applications, ensuring reliability in demanding operational conditions.
