Product Detailed Parameters
- Description：RES THIN FILM
- Series：-
- Mfr：KYOCERA AVX
- Package：Tray
- Function：Termination
- Frequency：-
- RF Type：-
- Secondary Attributes：-
- Mounting Type：Flange Mount
- Package / Case：-
- Supplier Device Package：-
- Grade：-
- Qualification：-
Download product information
Overview
The FR10300N0200JBK is a fixed thin film resistor manufactured by KYOCERA AVX. It features a resistance value of 200 ohms with a tolerance of 5%. The component has a power rating of 20W and operates within a temperature range from -55°C to +150°C. It utilizes a chassis mount package style and exhibits a temperature coefficient of 150 ppm/°C.
Feature Summary
- High power dissipation capability rated at 20 watts for robust thermal performance
- Thin film construction ensures precise resistance tolerance and stability
- Chassis mount design facilitates secure installation in industrial enclosures
Applications
- Industrial power supply circuits requiring high wattage resistors
- Load banking and testing equipment applications
- Chassis-mounted electronic assemblies needing stable resistance
Procurement Notes
Verify the specific mounting hole dimensions and terminal configuration against your chassis design before ordering. Confirm that the thermal management strategy supports the full 20W dissipation rating under your operating conditions. Ensure the voltage rating aligns with your circuit requirements to prevent dielectric breakdown during operation.
Selection Notes
Select this component when high power handling and precise resistance are required in a chassis-mount form factor. Consider the 150 ppm/°C temperature coefficient for thermal stability needs. Evaluate space constraints as chassis mount packages typically require dedicated mounting areas compared to surface mount alternatives.
Part Context
This part belongs to the fixed thin film resistor category from KYOCERA AVX. It is designed for applications demanding higher power ratings than standard through-hole or surface mount resistors can provide. The series offers reliability for industrial and commercial electronics where long-term stability is critical.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing thermal and mechanical constraints if considering alternative manufacturers.
