H2UE3P1D2G0100

Antennas RF Overview

The H2UE3P1D2G0100 is a surface-mount antenna module designed for LTE and 4G full-band applications. It operates across frequency ranges of 698MHz to 798MHz, 824MHz to 892MHz, 1.71GHz to 2.17GHz, and 2.5GHz to 2.69GHz. The component supports multiple wireless standards including GSM, WCDMA, LTE, and CDMA. It features a maximum power rating of 2W and utilizes solder termination. The physical height is limited to 6.00mm, making it suitable for compact device integration.

Antennas RF Feature Summary

• Supports comprehensive multi-standard wireless communication protocols
• Designed for surface-mount assembly with low profile dimensions
• Capable of handling up to 2W maximum power input

Antennas RF Applications

• LTE/4G mobile devices
• Global System for Mobile Communications (GSM) handsets
• Wideband Code Division Multiple Access (WCDMA) terminals
• Code Division Multiple Access (CDMA) equipment

Antennas RF Procurement Notes

Verify the specific datasheet version and mechanical drawings prior to procurement to ensure compatibility with your PCB layout and enclosure constraints. Confirm that the solder termination type aligns with your manufacturing process capabilities. Ensure that the operating frequency ranges fully cover the regulatory requirements for your target market regions. Cross-reference the RoHS compliance status with current environmental regulations applicable to your production facilities.

Antennas RF Selection Notes

Select this component when a single antenna solution is required to support diverse cellular bands across 2G, 3G, and 4G networks. Consider its 6.00mm height limit if vertical space within the device chassis is restricted. Evaluate the 2W power handling capability against your transmitter specifications to ensure safe operation under peak load conditions. Verify that the surface-mount package fits within your available footprint on the printed circuit board.

Antennas RF Part Context

This part belongs to Unictron Technologies Corporation's portfolio of wireless communication antennas. The manufacturer specializes in providing antenna modules and piezoelectric ceramic elements for various electronic applications. This specific model addresses the need for integrated RF solutions in modern mobile telecommunications hardware, supporting global band coverage requirements.

Antennas RF Replacement Considerations

H2B1MH3A2F0100 is listed as a related product by the same manufacturer, though it is an evaluation board rather than a direct component substitute. No other public confirmed substitute part numbers are identified in the provided documentation.
