HG2412P

$59.08

Description：ANTPATCH 2.4GHZ 11DBI
Series：HG
Mfr：L-com
Package：Bag

SKU:2b7b5274c268 Category: RF Antennas Brand: L-com

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

HG2412P is listed in the Antennas RF range at ChipApex. The manufacturer field lists L-com. Its product description is ANTPATCH 2.4GHZ 11DBI. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for HG2412P

Description：ANTPATCH 2.4GHZ 11DBI
Series：HG
Mfr：L-com
Package：Bag
RF Family/Standard：Bluetooth, General ISM, WiFi
Frequency Group：UHF (2GHz ~ 3GHz)
Frequency (Center/Band)：2.45GHz
Frequency Range：2.4GHz ~ 2.5GHz
Antenna Type：Panel
Number of Bands：1
VSWR：1.5
Return Loss：-
Gain：11.14dBi
Features：-
Termination：N Type Female
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Bracket Mount
Height (Max)：3.500" (88.90mm)
Applications：802.11b/g/n, Bluetooth, ISM, Wi-Fi, WLAN
Power - Max：200 W

Antennas RF datasheet and documents for HG2412P

HG2412P

Antennas RF Overview

The L-com HG2412P is a panel-mount RF antenna designed for the 2.4 to 2.5 GHz frequency range, supporting WiFi and WLAN applications. It features a 12 dBi gain and an 180-degree sector radiation pattern, providing wide-angle directional coverage. The antenna supports horizontal and vertical polarization and utilizes an N-type female connector for bracket mounting. This configuration ensures reliable signal transmission in wireless communication scenarios requiring specific directional focus.

Antennas RF Feature Summary

Provides 12 dBi gain for enhanced signal strength within the 2.4 to 2.5 GHz band
Features an 180-degree sector radiation pattern for wide-angle directional coverage
Supports both horizontal and vertical polarization options
Designed for panel mounting with an N-type female connector interface

Antennas RF Applications

WiFi network infrastructure deployment
WLAN system integration
ISM band wireless communication
Bluetooth connectivity solutions

Antennas RF Procurement Notes

Verify that the required connector type matches the N-type female specification on the HG2412P. Confirm compatibility with the intended 2.4 to 2.5 GHz operational frequency range. Ensure the mounting environment supports the panel-mount design and bracket requirements. Check for any specific environmental ratings if outdoor installation is planned, as datasheet details may vary by revision.

Antennas RF Selection Notes

Select this model when a directional 180-degree coverage pattern is required rather than omnidirectional. The 12 dBi gain is suitable for extending range in specific sectors. Consider the N-type connector for robust mechanical connections. Evaluate polarization needs, as this unit supports both horizontal and vertical orientations, allowing flexibility in antenna alignment relative to receiving devices.

Antennas RF Part Context

The HG2412P belongs to L-com's portfolio of RF antennas and wireless components. L-com specializes in industrial-grade interconnect solutions, including cables, connectors, and antennas. This product targets professional wireless networking applications, offering a balance of gain and beamwidth for structured coverage areas in commercial or industrial settings.

Antennas RF Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing mounting hardware and cable assemblies before considering alternative models from other manufacturers.
