Product Detailed Parameters
- Description：IC RF AMP VSAT 17GHZ-27GHZ MOD
- Series：-
- Mfr：Analog Devices Inc.
- Package：Box
- Frequency：17GHz ~ 27GHz
- P1dB：15dBm
- Gain：19dB
- Noise Figure：3dB
- RF Type：VSAT
- Voltage - Supply：8V ~ 16V
- Current - Supply：96mA
- Test Frequency：-
- Mounting Type：Connector Mount
- Package / Case：Module, SMA Connectors
- Supplier Device Package：Module
- Grade：-
- Qualification：-
Download product information
Overview
The HMC-C017 is a GaAs MMIC PHEMT low noise amplifier housed in a miniature, hermetic module. It operates within the frequency range of 17 to 27 GHz. The device provides high dynamic range performance with a gain of 18 dB and a noise figure of 2.75 dB. Key electrical specifications include a P1dB output power of 15 dBm and an IIP3 of 45 dBm. The component utilizes SMA connectors for interface.
Feature Summary
- Utilizes GaAs MMIC PHEMT technology for enhanced signal amplification
- Encapsulated in a miniature, hermetically sealed module for environmental protection
- Designed for high dynamic range operation in millimeter-wave applications
Applications
- VSAT communication systems
- Millimeter-wave radar systems
- Point-to-point microwave links
Procurement Notes
Verify part authenticity through authorized Analog Devices channels. Confirm package integrity and connector condition upon receipt. Check datasheet revisions for updated specifications. Ensure storage conditions meet moisture sensitivity level requirements. Validate compatibility with existing RF circuit designs before integration.
Selection Notes
Select this component for applications requiring low noise amplification in the W-band spectrum. Consider the hermetic packaging for harsh environments. Evaluate the 18 dB gain against system link budget requirements. Assess the 2.75 dB noise figure impact on overall receiver sensitivity. Verify SMA connector compatibility with board layout constraints.
Part Context
This module belongs to the HMC series of RF components from Analog Devices. It is designed for high-frequency applications where size and performance are critical. The hermetic construction distinguishes it from surface-mount alternatives, offering robustness for specialized industrial or military use cases.
Replacement Considerations
DigiKey lists the HMC-C017 as obsolete. No direct public substitute part numbers are confirmed in the provided documentation. Users should consult Analog Devices for current equivalent modules or redesign for available active parts.
