HSCSNBD010NDAA5

Pressure Sensors Transducers Overview

The HSCSNBD010NDAA5 is a differential pressure sensor from the TruStability HSC series, manufactured by Honeywell Sensing and Productivity Solutions. It features an analog voltage output ranging from 0.5V to 4.5V with a supply voltage of 4.95V to 5.05V. The device operates within a working pressure range of ±0.36PSI (±2.49kPa) and has a maximum pressure rating of ±12.65PSI (±87.21kPa). It utilizes PC pin termination in a 4-SIP package with dual ports on the same side. The sensor offers ±0.25% accuracy and includes amplified output and temperature compensation.

Pressure Sensors Transducers Feature Summary

• Amplified analog voltage output for direct signal processing
• Integrated temperature compensation for stable performance
• Differential pressure sensing capability with high overpressure tolerance

Pressure Sensors Transducers Applications

• Board-level installation in industrial systems
• HVAC differential pressure monitoring
• Flow measurement applications requiring low-pressure differentials

Pressure Sensors Transducers Procurement Notes

Verify component status as this part may be obsolete. Confirm availability of parametric equivalents such as HSCSNBD010NDAA5 or similar variants if original stock is unavailable. Ensure replacement matches electrical specifications including supply voltage, output range, and pressure ratings before integration.

Pressure Sensors Transducers Selection Notes

Select this model for applications requiring precise differential pressure measurement with analog voltage output. Consider the 4-SIP package and PC pin termination for through-hole mounting. Verify operating temperature range and accuracy requirements against application needs. Check for available substitutes if discontinuation is confirmed.

Pressure Sensors Transducers Part Context

Part of the TruStability HSC series, designed for reliable pressure sensing in industrial environments. Features include temperature compensation and amplified output, suitable for board-mounted installations. The series emphasizes stability and accuracy for critical monitoring tasks.

Pressure Sensors Transducers Replacement Considerations

HSCSNBD010NDAA5 is listed as a parametric equivalent substitute. Verify electrical compatibility and mechanical fit before adoption.

Pressure Sensors Transducers FAQ

What is the maximum pressure rating?

The maximum pressure rating is ±12.65PSI (±87.21kPa).

Does the sensor include temperature compensation?

Yes, the sensor features integrated temperature compensation.
