JPAD20 TO-92 2L

$4.88

Description：DIODE STANDARD 35V 10MA TO92
Series：PAD
Mfr：Linear Integrated Systems, Inc.
Package：Bulk

SKU:8d556aadbe9f Category: Single Diodes Brand: Linear Integrated Systems, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

JPAD20 TO-92 2L is listed in the Single Diodes range at ChipApex. The manufacturer field lists Linear Integrated Systems, Inc.. Its product description is DIODE STANDARD 35V 10MA TO92. Review the specifications below when checking this part for your BOM.

Single Diodes specifications for JPAD20 TO-92 2L

Description：DIODE STANDARD 35V 10MA TO92
Series：PAD
Mfr：Linear Integrated Systems, Inc.
Package：Bulk
Technology：Standard
Voltage - DC Reverse (Vr) (Max)：35 V
Current - Average Rectified (Io)：10mA
Voltage - Forward (Vf) (Max) @ If：1.5 V @ 5 mA
Speed：Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：20 pA @ 20 V
Capacitance @ Vr, F：1.5pF @ 5V, 1MHz
Mounting Type：Through Hole
Package / Case：TO-226-2, TO-92-2 (TO-226AC)
Supplier Device Package：TO-92
Operating Temperature - Junction：-55°C ~ 150°C
Grade：-
Qualification：-

Single Diodes datasheet and documents for JPAD20 TO-92 2L

JPAD20 TO-92 2L

Single Diodes Overview

The JPAD20 is a silicon signal diode from the PAD Series, designed for ultra-low leakage applications. It features a reverse breakdown voltage of at least -35V and a maximum reverse leakage current of -20pA at -20V. The device operates within a junction temperature range of -55°C to +150°C with continuous power dissipation up to 350mW.

Single Diodes Feature Summary

Direct replacement for Siliconix PAD series components
Ultra-low picoampere reverse leakage current
High reverse breakdown voltage capability

Single Diodes Applications

Operational amplifier input differential voltage limiting
Sample and hold circuit offset voltage reduction
Precision analog signal conditioning

Single Diodes Procurement Notes

Verify the specific package type against the datasheet, as the source document indicates SOT-23 packaging for the PAD series while the query specifies TO-92. Confirm manufacturer details with Linear Integrated Systems documentation to ensure component authenticity and correct part identification before procurement.

Single Diodes Selection Notes

Select this component when extremely low reverse leakage currents are critical for circuit performance. Ensure the operating environment stays within the specified thermal limits. Verify that the required reverse voltage does not exceed the absolute maximum ratings defined in the official specifications.

Single Diodes Part Context

Linear Integrated Systems manufactures the PAD series of picoampere diodes, leveraging expertise from historical semiconductor firms like Intersil and Micro Power Systems. These components are engineered for high-reliability discrete applications requiring precision and stability in analog signal paths.

Single Diodes Replacement Considerations

This component serves as a direct replacement for the Siliconix PAD series devices. No other substitute part numbers are documented in the provided source material.
