KBP202-BP

Description：BRIDGE RECT 1PHASE 200V 2A KBPR
Series：-

SKU:4c6dfff84530 Category: Bridge Rectifiers Brand: MCC (Micro Commercial Components)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：BRIDGE RECT 1PHASE 200V 2A KBPR
Series：-
Mfr：MCC (Micro Commercial Components)
Package：Bulk
Diode Type：Single Phase
Technology：Standard
Voltage - Peak Reverse (Max)：200 V
Current - Average Rectified (Io)：2:00 AM
Voltage - Forward (Vf) (Max) @ If：1.1 V @ 2 A
Current - Reverse Leakage @ Vr：5 µA @ 200 V
Operating Temperature：-55°C ~ 150°C (TJ)
Mounting Type：Through Hole
Package / Case：4-SIP, KBPR
Supplier Device Package：KBPR
Grade：-
Qualification：-

Download product information

KBP202-BP

Overview

The KBP202-BP is a single-phase bridge rectifier manufactured by Micro Commercial Components (MCC). It features a glass-passivated die construction and operates within a temperature range of -55°C to +150°C. The device provides an average forward current of 2.0A at a case temperature of 105°C, with a maximum peak forward surge current of 60A for an 8.3ms half-sine wave. It has a maximum recurrent peak reverse voltage of 200V and a maximum RMS voltage of 140V. The typical junction capacitance per element is 25pF at 4V reverse DC and 1MHz.

Feature Summary

Glass passivated die construction for high reliability
Suitable for printed circuit board mounting
RoHS compliant with lead-free finish

Applications

General purpose rectification in power supplies
AC to DC conversion circuits
Bridge rectifier applications requiring 200V blocking capability

Procurement Notes

Verify the component status as End-of-Life (EOL) or Not Recommended for New Designs (NRND) through official MCC channels before procurement. Confirm authenticity by purchasing only from authorized distributors to avoid counterfeit parts. Ensure the ordering suffix matches the required compliance specifications.

Selection Notes

Select this component when a 2A single-phase bridge rectifier with a 200V reverse voltage rating is required. Consider the thermal resistance of 10°C/W and the operating temperature limits during design. Verify that the PCB layout accommodates the KBPR package dimensions and pin spacing.

Part Context

This part belongs to the KBP2005 through KBP210 series of 2.0 Amp Glass Passivated Bridge Rectifiers. The series offers various voltage ratings from 50V to 1000V while maintaining consistent current handling capabilities. The KBP202 variant specifically addresses applications needing 200V peak reverse voltage.

Replacement Considerations

Check for direct substitutes within the KBP2005-KBP210 series if different voltage ratings are acceptable. Consult MCC documentation for alternative packages or manufacturers offering equivalent electrical characteristics and pinouts.
