LFSCM3GA40EP1-5FF1020C

Field Programmable Gate Array Overview

The LFSCM3GA40EP1-5FF1020C is a Field Programmable Gate Array (FPGA) from the LatticeSC/M family, manufactured using 90nm technology. It features 40,000 logic cells and operates at a core voltage of 1.2V. The device is housed in a 1020-pin Flip-Chip Ball Grid Array (FCBGA) package with dimensions of 33 x 33 mm. This component provides high-performance programmable logic suitable for complex digital design applications.

Field Programmable Gate Array Feature Summary

• Integrates embedded memory blocks and hierarchical clock networks for advanced system design
• Includes dedicated SERDES blocks with embedded Physical Coding Sublayer (PCS) functionality
• Supports high-speed parallel I/O operations up to 2 Gbps
• Features integrated Phase-Locked Loops (PLLs) and Delay-Locked Loops (DLLs) for precise clock management

Field Programmable Gate Array Applications

• High-end communication network systems
• Ethernet interface implementations
• PCI Express protocol support
• SPI4.2 standard integration
• High-speed storage controller designs

Field Programmable Gate Array Procurement Notes

This specific part number is listed as obsolete in official records. Verify current availability through authorized distributors or secondary market channels. Ensure compliance with RoHS directives if required by your supply chain standards. Confirm package integrity and pin compatibility before procurement to avoid integration issues with existing PCB layouts.

Field Programmable Gate Array Selection Notes

Select this FPGA when designing systems requiring approximately 40K logic cells and embedded memory resources. Consider the 1020-pin FCBGA package constraints for board space. Evaluate power requirements against the 1.2V core voltage specification. Ensure the design utilizes the available SERDES channels and clock management resources effectively for optimal performance.

Field Programmable Gate Array Part Context

The LatticeSC/M family targets high-performance applications in telecommunications and networking. These FPGAs combine flexible logic resources with specialized hardware accelerators. The series supports various high-speed serial interfaces and includes embedded ASIC blocks for enhanced throughput. This family addresses the need for low-power, high-density programmable solutions in evolving network standards.

Field Programmable Gate Array Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. The LFSC3GA40E-7FFN1020C is mentioned in comparison contexts but lacks explicit substitution confirmation. Consult Lattice Semiconductor directly for legacy product replacement strategies or updated family equivalents.
