LFSPXO009581BULK

Overview

The LFSPXO009581BULK is a standard clock oscillator manufactured by IQD Frequency Products, operating at a frequency of 3.6864 MHz. It utilizes a CMOS output format and requires a supply voltage of 3.3V. The device features enable/disable functionality for power management. It is housed in a compact 4-SMD, no-lead package with dimensions of 5.20mm x 3.20mm x 0.95mm. The component supports surface mount installation and operates within a temperature range of -40°C to +85°C.

Feature Summary

• CMOS output format for digital logic compatibility
• Enable/disable control functionality for power optimization
• Hermetically sealed ceramic package construction

Applications

• General purpose clock signal generation
• Embedded system timing references
• Digital circuit synchronization

Procurement Notes

Verify the specific suffix BULK indicates bulk packaging configuration when ordering. Confirm the exact frequency tolerance and load capacitance requirements against the official datasheet specifications for the target application environment. Ensure the supply voltage matches the 3.3V nominal requirement. Check for RoHS compliance status if required by project regulations. Validate the package dimensions against the PCB footprint design.

Selection Notes

Select this component when a precise 3.6864 MHz reference is needed with low profile surface mount constraints. Consider the CMOS output drive capability and enable pin utility for systems requiring dynamic power control. Evaluate the operating temperature range suitability for the intended environmental conditions. Compare package size against available board space limitations.

Part Context

This part belongs to the LFSPXO series of standard crystal oscillators from IQD Frequency Products. These devices are designed for applications requiring stable clock signals in compact electronic assemblies. The series offers various frequencies and package options to meet diverse design requirements while maintaining consistent performance characteristics across the product line.

Replacement Considerations

Consult official substitution guides for compatible alternatives. Verify electrical parameters and pinout compatibility before replacing.

FAQ

What is the output type of the LFSPXO009581BULK?

The output type is CMOS.

Does this oscillator support power control?

Yes, it includes enable/disable functionality.
