LM2707MF/NOPB

Description：IC LED DRV RGLTR PWM SOT23-8
Series：-
Mfr：Texas Instruments
Package：Tape & Reel (TR)

SKU:24b6b85c3e81 Category: LED Drivers IC Brand: Texas Instruments

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC LED DRV RGLTR PWM SOT23-8
Series：-
Mfr：Texas Instruments
Package：Tape & Reel (TR)
Type：DC DC Regulator
Topology：Step-Up (Boost)
Internal Switch(s)：Yes
Number of Outputs：1
Voltage - Supply (Min)：2.3V
Voltage - Supply (Max)：7V
Voltage - Output：18V
Current - Output / Channel：30mA
Frequency：-
Dimming：PWM
Applications：Backlight
Operating Temperature：-30°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：SOT-23-8
Supplier Device Package：SOT-23-8
Grade：-
Qualification：-

Download product information

LM2707MF/NOPB

Overview

The LM2707MF/NOPB is a DC-DC step-up (boost) regulator manufactured by Texas Instruments, designed primarily for LED backlight applications. It features an integrated power switch and supports PWM dimming control. The device operates with a maximum supply voltage of 7V and delivers a channel output current of 30mA, capable of reaching an output voltage of 18V. It is housed in an SOT-23-8 surface-mount package.

Feature Summary

Integrates a high-efficiency boost converter with an internal power switch
Supports Pulse Width Modulation (PWM) dimming for precise brightness control
Optimized for driving LED strings in portable electronic devices

Applications

LED backlight drivers for mobile phones and handheld devices
General-purpose step-up voltage conversion for low-power loads
Battery-powered systems requiring regulated higher voltage rails

Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm the specific suffix matches the required RoHS compliance status. Check for end-of-life (EOL) status implications on long-term supply availability. Ensure storage conditions adhere to moisture sensitivity level requirements prior to soldering.

Selection Notes

Select this component when a compact solution for low-current LED driving is required. The SOT-23-8 package offers space efficiency for dense PCB layouts. Consider the 30mA output limit against load requirements. Evaluate the 7V input range compatibility with the system's battery profile. Verify PWM dimming interface compatibility with the host controller.

Part Context

This part belongs to the Texas Instruments LM2707 series of LED driver ICs. It is specifically engineered for portable consumer electronics where size and power efficiency are critical. The series focuses on single-output boost configurations tailored for white LED arrays.
