LNA-40-04001200-40-25P

Overview

The LNA-40-04001200-40-25P is a low noise amplifier module from the L3 Narda-MITEQ LNA series, designed for VSAT applications. It operates within a frequency range of 4 GHz to 12 GHz. The device provides a typical gain of 40 dB with a noise figure of 3.5 dB. It delivers a P1dB output power of 20 dBm and requires a supply voltage of 15 V at a current draw of 400 mA. The component is supplied in a box package.

Feature Summary

• Provides high-gain signal amplification suitable for satellite communication systems
• Engineered for operation across a wide microwave frequency band
• Delivers stable performance with defined linearity characteristics

Applications

• VSAT uplink and downlink systems
• Satellite communications ground stations
• Microwave relay links

Procurement Notes

Verify the specific suffix '25P' against the manufacturer's official documentation to confirm pinout and connector specifications. Ensure the required 15V supply and 400mA current capacity are supported by the system design before integration. Cross-reference the active status and lead times directly with authorized distributors.

Selection Notes

Select this model when a 40 dB gain and 3.5 dB noise figure are required within the 4-12 GHz range. Consider the 20 dBm P1dB limit for linearity requirements. Evaluate thermal management needs due to the 15V/400mA power consumption. Compare against other LNA series variants if different frequency bands or gain levels are needed.

Part Context

This component belongs to the LNA series of RF amplifiers manufactured by L3 Narda-MITEQ. These modules are typically used in professional radio frequency and microwave subsystems. The part number structure indicates specific gain, frequency, and configuration parameters defined by the manufacturer's coding system.

Replacement Considerations

Consult official substitution guides for equivalent gain and frequency coverage. Verify interface compatibility and electrical parameter alignment before replacing.
