Product Detailed Parameters
- Description：TRANS 2PNP 45V 10MA SOT-23-6
- Series：-
- Mfr：Linear Integrated Systems, Inc.
- Package：Cut Tape (CT)
- Transistor Type：2 PNP (Dual)
- Current - Collector (Ic) (Max)：10mA
- Voltage - Collector Emitter Breakdown (Max)：45V
- Vce Saturation (Max) @ Ib, Ic：500mV @ 100µA, 1mA
- Current - Collector Cutoff (Max)：200pA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce：150 @ 1mA, 5V
- Power - Max：500mW
- Frequency - Transition：200MHz
- Operating Temperature：150°C (TJ)
- Mounting Type：Surface Mount
- Package / Case：SOT-23-6
- Supplier Device Package：SOT-23-6
- Grade：-
- Qualification：-
Download product information
Overview
The LS351 is a high-performance bipolar transistor from Linear Integrated Systems, Inc., housed in a surface-mount SOT-23-6 package. It features a collector current of 10mA and a collector-emitter breakdown voltage of 45V. The device exhibits a saturation voltage of 500mV, a minimum DC current gain (hFE) of 150, and a transition frequency of 200MHz. It supports an operating temperature up to 150°C.
Feature Summary
- High-frequency operation capability with a transition frequency of 200MHz
- Surface-mount construction for automated assembly integration
- Enhanced thermal stability supporting extended operating temperatures
Applications
- High-frequency signal amplification circuits
- General-purpose switching applications
- Precision instrumentation systems
Procurement Notes
Verify the specific manufacturer datasheet to confirm pinout configurations and electrical tolerances. Ensure compliance with RoHS directives as indicated by the component designation. Cross-reference the exact part number with official distributor catalogs to validate availability and authenticity before procurement.
Selection Notes
Select this component when high-frequency performance and compact surface-mount packaging are required. The specified current gain and breakdown voltage suit general amplification tasks. Evaluate thermal requirements against the maximum operating temperature limit to ensure reliable circuit operation under load conditions.
Part Context
Linear Integrated Systems, Inc. specializes in small-signal discrete semiconductors. The LS351 belongs to a series of high-performance bipolar transistors designed for demanding electronic applications. This specific model represents a surface-mount solution within their broader portfolio of precision semiconductor devices.
Replacement Considerations
Consult official substitution guides for compatible alternatives. Verify that any replacement matches the SOT-23-6 package and meets or exceeds the 45V breakdown voltage and 200MHz frequency specifications.
