LT8386EV#PBF

LED Driver IC Overview

The LT8386EV#PBF is an evaluation board for the LT8386, a monolithic synchronous step-up DC-to-DC converter. This device integrates a 60V, 3A silent switcher and utilizes fixed frequency peak current control. It provides PWM dimming capabilities for LED applications. The component operates within a junction temperature range of -40°C to 125°C. It is housed in a 28-lead LQFN (4x5) package. The board facilitates testing of the regulator's performance in boost configurations.

LED Driver IC Feature Summary

• Integrates a 60V, 3A synchronous silent switcher for low EMI operation
• Provides PWM dimming control for LED driver applications
• Utilizes fixed frequency peak current mode control architecture

LED Driver IC Applications

• LED lighting systems
• Display backlighting
• Indicator circuits

LED Driver IC Procurement Notes

Verify that the specific part number corresponds to the evaluation board variant rather than the standalone IC. Confirm package type matches the 28-LQFN specification. Ensure compatibility with the intended input voltage range and load requirements before integration. Check datasheet revisions for any updates to thermal or electrical characteristics.

LED Driver IC Selection Notes

Select this component when high efficiency and low electromagnetic interference are required in space-constrained designs. The integrated silent switcher technology reduces noise compared to traditional converters. Consider the 60V output capability for driving series LED strings. Evaluate the PWM dimming interface for precise brightness control needs.

LED Driver IC Part Context

This evaluation module supports the development of power solutions using Analog Devices' synchronous buck-boost technology. It allows engineers to validate circuit performance before committing to custom PCB layouts. The platform demonstrates the converter's ability to handle wide input voltage ranges while maintaining stable output regulation under varying load conditions.

LED Driver IC Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
